ENGLISH
FRONT PANEL CONTROL
Menu Button ( )
Scroll Down or Aspect Ratio shortcut keys(
)
Scroll Up or Brighness/Contrast/ECO Mode Button(
)
Select / Auto Button ( )
Power Indicator
Blue: Normal operation
Orange: Power Management
The monitor enters into power management mode which reduces the power
consumption to less than 2W when receiving no horizontal and/or vertical
sync signal.
Power Switch ( )
AC Connector (Power IN)
Audio Connector(AUDIO IN)
D-SUB mini 15pin Connector (VGA)
Keyhole for Security Lock *
Speakers
CONTROLS AND CONNECTORS
*You can fasten a security lock and cable to prevent the monitor from being removed
without your permission.
NOTE
BEFORE YOU OPERATE THE MONITOR 6
<Front>
<Back>
NOTE
11

   
11
1
2
It can display in the center of the screen with 4:3 or 5:4 aspect ratio when input video resolution is 4:3
or 5:4.
Press the
Button when the Menu is not displayed.
