14 1440 × 900 55.94 59.89
15 1440 × 900 55.469 59.901
16 1600 × 900 60.0 60.0
17 1600 × 1000 61.648 60.00
18 1600 × 1200 75.00 60.00
19 1680 × 1050 65.29 60.00
20 1920 × 1080 67.5 60.00
ZR24w Model
Table B-4 Factory Preset Modes
Preset Pixel Format Horz Freq (kHz) Vert Freq (Hz)
1 640 × 480 31.469 59.940
2 720 × 400 31.469 70.087
3 800 × 600 37.879 60.317
4 1024 × 768 48.363 60.004
5 1280 × 960 60.00 60.00
6 1280 × 1024 63.981 60.02
7 1440 × 900 55.935 59.887
8 1600 × 1200 75.00 60.00
9 1680 × 1050 65.29 60.00
10 1920 × 1080 67.50 60.00
11 1920 × 1200 74.038 59.95
12 1920 × 1200 74.556 59.885
Entering User Modes
The video controller signal may occasionally call for a mode that is not preset if:
●
You are not using a standard graphics adapter.
●
You are not using a preset mode.
It this occurs, you may need to readjust the parameters of the monitor screen by using the on-screen
display. Your changes can be made to any or all of these modes and saved in memory. The monitor
automatically stores the new setting, then recognizes the new mode just as it does a preset mode. In
addition to the factory preset modes, there are fifteen to twenty user modes, depending on the model,
that can be entered and stored.
Table B-3 Factory Preset Modes (continued)
ENWW Entering User Modes 37
