7.
Disconnect the display panel cable (3) from the display panel, and then remove the panel (4).
Reverse this procedure to replace the panel.
Keyboard
NOTE: The keyboard spare part kit includes a keyboard cable.
Description Spare part number
Black keyboard:
●
For use in Canada 701684-DB1
●
For use in France 701684-051
●
For use in Germany 701684-041
●
For use internationally 701684-B31
●
For use in Israel 701684-BB1
●
For use in Japan 701684-291
●
For use in Latin America 701684-161
●
For use in Nordic countries 701684-DH1
●
For use in Portugal 701684-131
●
For use in Saudi Arabia 701684-171
●
For use in Spain 701684-071
●
For use in South Korea 701684-AD1
●
For use in Taiwan 701684-AB1
Component replacement procedures
47
