Q1860-90918 8 Parts and diagrams 269
Table 68. Internal components (2 of 4)
Item number Part number Quantity Description
1 RG5-3519-020CN 1 Pickup roller assembly, Tray 1
1B RB2-1820-020CN 1 Roller, Tray 1 pickup
2 RG5-3545-000CN 1 Power inlet assembly
3 RB1-6179-000CN 2 Pickup shaft bushing—trays 1 and 2
4 RF5-2421-000CN 1 Shutter lever
5 RB2-1744-000CN 1 On/off switch
6 RB2-1780-000CN 1 Paper guide
7 RS5-1392-000CN 2 Tray 1 and 2 pickup shaft left bushing
10 RB1-2190-000CN 1 Tray 2 spring
11 RB1-6130-000CN 1 Gear, pickup, Tray 1
12 RB1-6177-000CN 2 Pickup shaft bushing—trays 1 and 2
13 RB2-1731-000CN 1 Switch rod
14 RB3-0352-000CN 1 Grounding plate/fan housing
15 RB2-1736-000CN 1 Grounding plate
16 RF5-2397-000CN 1 Tray 2 rail left
17 RF5-2398-000CN 1 Tray 2 rail right
18 RH7-1552-000CN 1 Fan
19 RS5-0695-000CN 1 Tray 2 shaft gear
20 RS5-2434-000CN 1 Spring
21 RB2-1774-000CN 1 Cartridge guide left
22 RB2-1775-000CN 1 Cartridge guide right
