1 7HPSODWH5HYLVLRQ%Page7

36*LQVWUXFWLRQVIRUWKLVWHPSODWHDUHDYDLODEOHDW(/0)

WorkInstructs

DocumentNo.:DisassemblyWI Step:5

Name:DisassembleCcover Date:2011Ͳ1Ͳ13



Fixturelist(Fixturestandard) Qty Fixturelist(Fixturestandard) Qty

CrossHeadofScrewsDriver 1 

Pointforattention:Iffindingsomedefects,noticethegafferandassess.



Fig.3

Fig.2

Step:

1.PullouttheTPcable.(Fig.1)

2.Loosentwoscrewstheandtake

offthePOWERBUTTON

BOARD.(Fig.2)

3.Loosensevenscrewsand

removetheTPbracket.(Fig.3)



Fig.1


