HP Fingerprint Sensor
Mobile Voltage
Operation
3.0V-3.6V Single Supply
Operating Temperature
32° – 158°F (0° – 70°C)
Current Consumption @
3.3V
Less than 70 mA peak imaging and scrolling
Less than 25 mA hardware finger detection
Advanced Power Management
High-Rate Image Capture
Up to 240 image frames /sec
ESD Resistance
IEC 61000-4-2 Level 4 (±15KV)
Detection Matrix
192 x 16 Pixels
9.7 mm x 0.81 mm
500 ppi High-Resolution Images
Audio
Hardware
Implementation
ADI1984A High Definition CODEC
Touch-Sensitive Volume
Controls
Volume up, volume down, and mute
Full Duplex
Yes
Sound Blaster Pro
compatible
Yes
Microphone In
Stereo
Headphone/Line Out
Stereo
Integrated Mono Speaker
Power Rating
2 Watts
Impedance
4 Ohms
Communications
Integrated Intel Gigabit
Network Connection
(10/100/1000 NIC)
82567LM
Ethernet Features
10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-
30)
1000 Mbit/s operation (1000BASE-T; IEEE 802.3z and 802.3ab; IEEE
802.3 clauses 34-42)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100
Mbit/s
IEEE 802.1p QoS (Quality of Service) Support
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)
Power Management
ACPI compliant -- multiple power modes
Situation-sensitive features reduce power consumption
Performance Features
TCP/IP/UDP Checksum Offload (configurable)
Manageability
Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft
Wake-Up Frame); Wake-on-LAN from off (Magic Packet only)
PXE 2.1 Remote Boot
Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x,
QuickSpecs
HP EliteBook 2530p Notebook PC
Technical Specifications
DA - 13101 Worldwide QuickSpecs — Version 8 — 2.5.2009
Page 23
