Top Panel Assembly
Ref.
No:
Part
No:
Description:
Ref.
No:
Part
No:
Description:
Image 1:
VENTURI TOP PANEL 26" (M1, M2, M3, M4)0121R00009PDG11
VENTURI TOP PANEL 29" (M5, M6, M7, M8, M9,
M10)
0121R00011PDG11
VENTURI TOP PANEL 35" (M11, M12, M13)0121R00013PDG11
WIRE GRILL 26" (M1, M2, M3, M4)0152R00000P21
WIRE GRILL 29" (M5, M6, M7, M8, M9, M10)0152R0000821
WIRE GRILL 35" (M11, M12, M13)0152R0000921
COND MOTOR 1/12 HP, 1 SP, 8 PL (M15)0131M00019P31
COND MOTOR 1/12 HP, 2 SP, 8 PL (M3, M4)0131M0002731
COND MOTOR 1/4 HP, 1 SP, 8 PL (M19)0131M00061S31
COND MOTOR 1/4 HP, 2 SP, 8 PL (M11, M12, M13)0131M00015PS31
COND MOTOR 1/6 HP, 1 SP, 8 PL (M14, M16, M17,
M18)
0131M00060S31
COND MOTOR 1/6 HP, 2 SP, 8 PL (M1, M2, M5,
M6, M7, M8, M9, M10)
0131M00017PS31
HEX NUT (M1, M2, M3, M4, M5, M6, M7, M8, M9,
M10, M11, M12, M13)
M028080141
FAN BLADE 20 INCH (M3, M4, M15)0150M00001P51
FAN BLADE 20" CCW (M1, M2, M14)0150M00012S51
FAN BLADE 22" TNT2203-25 (M7, M8, M9, M10,
M17)
0150M00008S51
FAN BLADE 26" ALUM CCW (M11, M12, M13, M19)10625738S51
FAN BLADE TYPE 2 (M5, M6, M16, M18)B1086764S51
AMANA LOGO CAP (M1, M2, M3, M4, M5, M6, M7,
M8, M9, M10, M11, M12, M13)
0161R00008P61
SCREW #10 X 1/2, A, SLOT, SR, BLACK (M1, M2,
M3, M4, M5, M6, M7, M8, M9, M10, M11, M12, M13)
0163M00003P71
TOP PANEL 26" (M14, M15)0121R00008PDG111
TOP PANEL 29" (M16, M17, M18)0121R00010PDG111
TOP PANEL 35" (M19)0121R00012PDG111
CONDUIT (M1, M2, M3, M4)0161R00000P121
CONDUIT (M14, M15)0161R00001P121
CONDUIT (M5, M6, M7, M8, M9, M10, M17)0161R00002P121
CONDUIT (M16, M18)0161R00003P121
CONDUIT (M11, M12, M13, M19)0161R00004P121
VENTURI RING 22" (M17)0161L00000131
VENTURI RING 35" (M19)0161R00007P131
ACORN NUT 5/16 HEX BLACK (M14, M15, M16,
M17, M18, M19)
0163M00006P141
Expanded Model Nomenclature
M1 - ASX140181BA
M2 - ASX140181CA
M3 - ASX140241BA
M4 - ASX140241CA
M5 - ASX140301BA
M6 - ASX140301CA
M7 - ASX140361BA
M8 - ASX140361CA
M9 - ASX140421CA
M10 - ASX140421DA
M11 - ASX140481BA
M12 - ASX140481CA
M13 - ASX140601BA
M14 - SSX140181BA
M15 - SSX140241BA
M16 - SSX140301BA
M17 - SSX140361BA
M18 - SSX140421CA
M19 - SSX140481BA
5
RP-536E
