prodUCt speCifiCations
prodUCt speCifiCations
4 www.goodmanmfg.com SS-CPC36-72
p
rodUCt
s
peCifiCations
— CpC048 B m
odels
CPC048
XXX1DXXX
CPC048
XXX3DXXX
CPC048
XXX3BXXX
CPC048
XXX4BXXX
CPC048
XXX7BXXX
Total BTU/h 45,500 45,500 45,500 45,500 45,500
Sensible BTU/h 35,000 35,000 35,000 35,000 35,000
SEER / EER 13.0 / 11.3 13.0 / 11.3 13.0 / 11.3 13.0 / 11.3 13.0 / 11.3
Decibels 78 78 78 78 78
ARI Reference #s
4385053 4385054 4385054 4385055 4397605
Motor Type Direct Drive Direct Drive Belt Drive Belt Drive Belt Drive
Indoor Nominal CFM 1,600 1,600 1,600 1,600 1,600
Motor Speed Tap (Cooling) Medium Medium -- -- --
Indoor Motor FLA (Cooling) 2.87 2.87 3.8 1.9 2.3
Horsepower - RPM ½ -1,000 ½ -1,000 1.0 - 1,725 1.0 - 1,725 1.5 - 1,725
Piston Size (Cooling) 0.076 0.076 0.076 0.076 0.076
Filter Size (Qty) (4) 14" x 20" x 2" (4) 14" x 20" x 2" (4) 14" x 20" x 2" (4) 14" x 20" x 2" (4) 14" x 20" x 2"
Drain Size (NPT) ¾" ¾" ¾" ¾" ¾"
R-410A Refrigerant Charge (oz.) 103 103 103 103 105
Evaporator Coil Face Area (²) 7.0 7.0 7.0 7.0 7.0
Rows Deep / Fins per Inch 4 / 16 4 / 16 4 / 16 4 / 16 4 / 16
# of Wheels (D x W) --- --- 1 (11" x 10") 1 (11" x 10") 1 (11" x 10")
Motor Sheave --- --- VL44 X 5/8 VL44 X 5/8 VL44 X 5/8
Blower Sheave / Belt --- --- AK66 x 1 / AX55 AK66 X 1 AK66 X 1
Quanty of Condenser Fan Motors 1 1 1 1 1
Horsepower - RPM ¼ - 1,090 ¼ - 1,090 ¼ - 1,090 ¼ - 1,090 ¼ - 1,075
Fan Diameter / # Fan Blades 22 / 4 22 / 4 22 / 4 22 / 4 22 / 4
Outdoor Nominal CFM 3,800 3,800 3,800 3,800 3,800
Face Area (²) 17 17 17 17 17
Rows Deep / Fins per Inch 1 / 24 1 / 24 1 / 24 1 / 24 1 / 24
Quanty / Stage 1 / Single 1 / Single 1 / Single 1 / Single 1 / Single
Type Scroll Scroll Scroll Scroll Scroll
Compressor RLA / LRA 20 / 109 13.1/ 83.1 13.1/ 83.1 6.1/ 41 4.4/ 33
Voltage-Phase-Frequency 208/230-1-60 208/230-3-60 208/230-3-60 460-3-60 575-3-60
Outdoor Fan FLA 1.40 1.40 1.40 0.80 0.60
Total Unit Amps 24.1 17.4 18.3 8.8 7.3
Min. Circuit Ampacity¹ 29 21 22 10 8
Max. Overcurrent Protecon (amps)² 45 30 30 15 15
Power Supply Conduit Hole 1.125" 1.125" 1.125" 1.125" 1.125"
Low-Voltage Conduit Hole ½" ½" ½" ½" ½"
535 535 535 535 535
560 560 560 560 560
¹ Wire size should be determined in accordance with Naonal Electrical Codes. Extensive wire runs will require larger wire sizes.
² May use fuses or HACR-type circuit breakers of the same size as noted.
Note: Always check the S&R plate for electrical data on the unit being installed.
