PACKAGE COOLING SPECIFICATIONS
30
IMPORTANT: While this data is presented as a guide, it is important to electrically connect the unit and properly size wires and fuses/circuit breakers
in accordance with the National Electrical Code and/or all local codes. Data shown is w/o electric heaters.
(1)
Maximum Overcurrent Protection Device: MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
*
Calculated external filter size based on air velocity of 300 ft/min.
Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
Unit specifications are subject to change without notice. ALWAYS refer to the units serial plate for the most up-to-date general and electrical information.
GPC14[24-30]H41AB
MODELS WITH 5MM COILS
GPC1424H41AB GPC1430H41AB
COOLING
COOLING CAPACITY, BTUH
24,600 28,400
CAPACITY
SEER / EER
14.5 / 12.1 14.0 / 12.1
UNIT
VOLTAGE (NAMEPLATE)
208-230/1/60 208-230/1/60
ELECTRICAL
AMPS (TOTAL)
16.1 15.76
SPECIFICATION
MINIMUM CIRCUIT AMPACITY
19.5 19
MAXIMUM OVERCURRENT PROTECTION
(1)
30 30
COMPRESSOR
TYPE
SCROLL SCROLL
RATED LOAD AMPS
13.5 12.8
LOCKED ROTOR AMPS
58.3 64
CONDENSER
HORSEPOWER
1/6 1/6
FAN MOTOR
RPM
815 815
FULL LOAD AMPS 1.1 1.1
LOCKED ROTOR AMPS
1.7 1.7
CONDENSER FAN
BLADE DIAMETER (INCHES) / # OF BLADES
22 / 2 22 / 2
CONDENSER
FACE AREA - SQ. FT.
12.3 12.3
COIL
NUMBER OF ROWS
11
FINS PER INCH 26 26
EVAPORATOR
HORSEPOWER - NO. OF SPEEDS
1/2 - 5 1/2 - 5
BLOWER
FULL LOAD AMPS
1.5 1.86
MOTOR
LOCKED ROTOR AMPS
NA NA
MOTOR SPEED TAP - COOLING
T2 T2
RPM
1050 1050
EVAPORATOR
DIAMETER X WIDTH (INCHES)
10 X 8 10 X 8
BLOWER
HI EFFICIENCY COOLING CFM
850 1,050
FAN ONLY COOLING CFM
800 950
MAX EXTERNAL STATIC PRESS ("w.c.)
0.5 0.5
EVAPORATOR
FACE AREA - SQ. FT.
5.25 5.25
COIL
NUMBER OF ROWS
33
FINS PER INCH
16 16
GENERAL
FILTER SIZE - SQ. FT. *
20 x 20 x 1 20 x 25 x 1
INFORMATION
DRAIN SIZE (INCHES)
3/4" 3/4"
EXPANSION DEVICE ORIFICE (0.057) ORIFICE (0.062)
REFRIGERANT CHARGE R-410A (Oz.) 59 53
POWER SUPPLY CONDUIT KNOCKOUT SIZE (IN.)
3/4, 1, 1-1/4 3/4, 1, 1-1/4
LOW VOLTAGE CONDUIT KNOCKOUT SIZE (IN.) 1/2 1/2
SHIPPING WEIGHT LBS.
290 290
OPERATING WEIGHT LBS.
280 280
