COOLING PERFORMANCE DATA
GPC1548M41*
MODEL: GPC1548M41
EXPANDED PERFORMANCE DATA
COOLING OPERATION
Design Subcooling, 7 °F @ the liquid access fitting connection AHRI 95 test conditions. Design Superheat 5°F @ the compressor suction access fitting connection.
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 45.5 46.5 49.6 53.1 44.4 45.4 48.5 51.8 43.3 44.3 47.3 50.6 42.3 43.2 46.2 49.4 40.2 41.1 43.9 46.9 37.2 38.0 40.6 43.4
S/T 0.89 0.84 0.68 0.51 0.93 0.87 0.71 0.53 0.95 0.89 0.72 0.54 1.00 0.92 0.75 0.56 1.00 0.95 0.78 0.58 1.00 0.96 0.78 0.58
Delta T25242016252421172524211726 24 21 172424211623221915
1519 KW 2.81 2.89 3.00 3.12 3.08 3.17 3.29 3.42 3.32 3.41 3.55 3.69 3.54 3.63 3.77 3.92 3.72 3.81 3.96 4.12 3.87 3.97 4.13 4.29
AMPS 12.8 13.1 13.5 13.9 13.7 14.0 14.4 14.9 14.8 15.1 15.6 16.1 15.7 16.1 16.5 17.1 16.6 17.0 17.5 18.1 17.5 17.9 18.5 19.2
HI PR 242 260 275 287 271 292 308 322 309 332 351 366 351 378 399 417 395 426 449 469 437 470 496 518
LO PR 111 118 129 138 117 125 136 145 122 130 142 151 128 136 149 159 134 143 156 166 139 148 161 172
MBh 44.1 45.1 48.2 51.5 43.1 44.1 47.1 50.3 42.1 43.0 45.9 49.1 41.1 42.0
44.8
47.9 39.0 39.9 42.6 45.5 36.1 36.9 39.4 42.2
S/T 0.85 0.80 0.65 0.49 0.88 0.83 0.67 0.50 0.91 0.85 0.69 0.52 0.93 0.88
0.71
0.53 0.97 0.91 0.74 0.55 0.98 0.92 0.75 0.56
Delta T26252117262522172625221726 25
22
17 26 25 21 17 24 23 20 16
80 1350 KW 2.78 2.86 2.97 3.09 3.05 3.13 3.26 3.39 3.29 3.38 3.51 3.65 3.50 3.59
3.74
3.88 3.68 3.78 3.93 4.08 3.83 3.93 4.09 4.25
AMPS 12.7 13.0 13.3 13.8 13.6 13.9 14.3 14.8 14.7 15.0 15.4 16.0 15.6 15.9
16.4
17.0 16.5 16.9 17.4 18.0 17.4 17.8 18.3 19.0
HI PR 239 258 272 284 269 289 305 318 306 329 347 362 348 374
395
412 391 421 445 464 433 465 492 513
LO PR 110 117 128 136 116 124 135 144 121 129 140 149 127 135
147
157 133 142 155 165 138 146 160 170
MBh 40.7 41.6 44.5 47.5 39.8 40.7 43.4 46.4 38.8 39.7 42.4 45.3 37.9 38.7 41.4 44.2 36.0 36.8 39.3 42.0 33.3 34.1 36.4 38.9
S/T 0.82 0.77 0.63 0.47 0.85 0.80 0.65 0.49 0.87 0.82 0.67 0.50 0.90 0.84 0.69 0.51 0.93 0.88 0.71 0.53 0.94 0.88 0.72 0.54
Delta T26252217262522182625221827 25 22 182625221724232016
1181 KW 2.70 2.77 2.88 3.00 2.96 3.04 3.16 3.29 3.19 3.28 3.41 3.54 3.40 3.49 3.62 3.77 3.57 3.66 3.81 3.96 3.72 3.82 3.97 4.13
AMPS 12.4 12.7 13.0 13.4 13.3 13.6 14.0 14.4 14.3 14.6 15.1 15.6 15.2 15.5 16.0 16.5 16.1 16.4 16.9 17.5 16.9 17.3 17.9 18.5
HI PR 232 250 264 275 261 280 296 309 296 319 337 351 338 363 384 400 380 409 432 450 420 452 477 497
LO PR 107 114 124 132 113 120 131 140 117 125 136 145 123 131 143 152 129 137 150 160 133 142 155 165
NOTE: Shaded area reflects AHRI rating conditions
MBh 46.3 47.1 49.4 52.7 45.2 46.1 48.2 51.5 44.1 45.0 47.1 50.2 43.0 43.9 45.9 49.0 40.9 41.7 43.6 46.6 37.9 38.6 40.4 43.1
S/T 0.94 0.90 0.82 0.66 0.97 0.94 0.84 0.69 0.99 0.96 0.87 0.70 1.00 0.99 0.89 0.73 1.00 1.00 0.93 0.75 1.00 1.00 0.94 0.76
Delta T26262421272625212726252126 26 25 222525252123232320
1519 KW 2.84 2.92 3.03 3.15 3.11 3.20 3.32 3.46 3.36 3.45 3.58 3.72 3.57 3.67 3.81 3.96 3.75 3.85 4.00 4.16 3.91 4.01 4.17 4.34
AMPS 12.9 13.2 13.6 14.0 13.8 14.1 14.6 15.0 14.9 15.2 15.7 16.2 15.8 16.2 16.7 17.3 16.8 17.1 17.7 18.3 17.7 18.1 18.7 19.3
HI PR 244 263 278 289 274 295 311 325 312 335 354 369 355 382 403 421 399 430 454 473 441 475 501 523
LO PR 112 119 130 139 119 126 138 147 123 131 143 153 130 138 150 160 136 144 158 168 140 149 163 174
MBh 44.9 45.8 47.9 51.1 43.9 44.7 46.8 50.0 42.8 43.6 45.7 48.8 41.8 42.6 44.6 47.6 39.7 40.5 42.4 45.2 36.8 37.5 39.2 41.9
S/T 0.89 0.86 0.78 0.63 0.93 0.89 0.81 0.65 0.95 0.92 0.83 0.67 0.98 0.95 0.85 0.69 1.00 0.98 0.89 0.72 1.00 0.99 0.89 0.72
Delta T27272522282726222827262228 27 26 222727262225252421
85 1350 KW 2.81 2.89 3.00 3.12 3.08 3.17 3.29 3.42 3.32 3.41 3.55 3.69 3.54 3.63 3.77 3.92 3.72 3.81 3.96 4.12 3.87 3.97 4.13 4.29
AMPS 12.8 13.1 13.5 13.9 13.7 14.0 14.4 14.9 14.8 15.1 15.6 16.1 15.7 16.1 16.5 17.1 16.6 17.0 17.5 18.1 17.5 17.9 18.5 19.2
HI PR 242 260 275 287 271 292 308 322 309 332 351 366 351 378 399 417 395 426 449 469 437 470 496 518
LO PR 111 118 129 138 117 125 136 145 122 130 142 151 128 136 149 159 134 143 156 166 139 148 161 172
MBh 41.4 42.3 44.3 47.2 40.5 41.3 43.2 46.1 39.5 40.3 42.2 45.0 38.6 39.3 41.2 43.9 36.6 37.3 39.1 41.7 33.9 34.6 36.2 38.6
S/T 0.86 0.83 0.75 0.61 0.89 0.86 0.78 0.63 0.91 0.88 0.80 0.65 0.94 0.91 0.82 0.67 0.98 0.95 0.85 0.69 0.99 0.95 0.86 0.70
Delta T28272622282826232828262328 28 26 232827262226262421
1181 KW 2.73 2.80 2.91 3.03 2.99 3.07 3.19 3.32 3.22 3.31 3.44 3.58 3.43 3.52 3.66 3.81 3.60 3.70 3.85 4.00 3.75 3.85 4.01 4.17
AMPS 12.5 12.8 13.1 13.6 13.4 13.7 14.1 14.5 14.4 14.7 15.2 15.7 15.3 15.7 16.1 16.7 16.2 16.6 17.1 17.7 17.1 17.5 18.0 18.7
HI PR 235 252 267 278 263 283 299 312 299 322 340 355 341 367 387 404 384 413 436 455 424 456 482 502
LO PR 108 115 125 133 114 121 132 141 118 126 138 146 124 132 144 154 130 139 151 161 135 143 157 167
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is AHRI Rating Conditions KW = Total system power
High and low pressures are measured at the liquid and suction access fittings. AMPS: Unit amps (comp.+ evaporator + condenser fan motors)
