1. PREFACE
This service manual provides various service information, including the mechanical and electrical parts, etc.
This room air conditioner was manufactured and assembled under a strict quality control system.
The refrigerant is charged at the factory. Be sure to read the safety precautions prior to servicing the unit.
1.1 FEATURES
• DESIGNED FOR COOLING ONLY
• BUILT-IN ADJUSTABLE THERMOSTAT
• WASHABLE ONE-TOUCH FILTER
• COMPACT SIZE
1.2 SPECIFICATIONS
• POWERFUL
MODLES
ITEMS
COOLING CAPACITY (BTU/h) 5,100
POWER SUPPLY (Phase,V,Hz) 1P,115V,60HZ
INPUT (W) 520
OPERATING CURRENT (AMP.) 4.8
REFRIGERANT CONTROL CAPILLARY TUBE
REFRIGERANT CHARGE (R-22) 205g (7.05oz)
INSIDE FAN TURBO FAN
OUTSIDE FAN PROPELLER FAN WITH SLINGER RING
AIR DISCHARGE 2-WAY (RIGHT AND LEFT)
CHASSIS TOP-DOWN
OVERLOAD PROTECTOR FOR COMPRESSOR
INTERNAL PROTECTOR FOR FAN MOTOR
TEMPERATURE CONTROL THERMOSTAT
FAN MOTOR 6 POLES,16W
PROTECTOR
