19
MEDIUM CHASSIS "M" SERIES PARTS LIST
* PARTS NOT SHOWN
MEDIUM CHASSIS 208/230 VOLT - 2006
REF DESCRIPTION PART NO# EM 230 KM 230 RM 230 SM 230 YM 230 CODE
ELECTRICAL PARTS
EM18L34-A
EM24L35-A
KM18L30-A
KM21L30-A
KM24L30-A
RM18L30-A
RM24L30-A
SM18L30A-A
SM21L30-B
SM24L30-A
YM18L34-A
1 THERMOSTAT 61822400 1 1 120
1 THERMOSTAT 61822500 11111 120
1 THERMOSTAT 61828400 1 120
* RESISTOR 61808001 1111111 1 200
* THERMOSTAT, DEF. 61350313 1 122
2 ELECTRONIC BOARD 61921174 111 331
* REMOTE CONTROL 61826605 111 350
OVERLOAD 61764522 1 190
OVERLOAD 61764532 1 190
* OVERLOAD 61764557 1 1 1 190
4 CAPACITOR 61080557 1 1 150
4 CAPACITOR 61080529 11111150
4 CAPACITOR 61080534 1 1 1 1 150
5 SUPPLY CORD 60500140 1 1 220
5 SUPPLY CORD 60500102 1 1 1 1 1 220
5 SUPPLY CORD 60500141 1 220
5 SUPPLY CORD 60500103 1 1 1 220
6 SWITCH SYS. 8 POS. 60607204 1 1 1 130
6 SWITCH SYS. 6 POS. 60607205 11111 130
7 SWITCH (YES - NO) 61806102 1111111 1 132
8 FAN MOTOR 61871432 1111111111 1 110
* SOLENOID COIL 25063600 1 240
8A HEATER 61878617 1 210
8A HEATER 61878601 1 1 210
REF DESCRIPTION PART NO# EM 230 KM 230 RM 230 SM 230 YM 230 CODE
REFRIGERATION PARTS
EM18L34-A
EM24L35-A
KM18L30-A
KM21L30-A
KM24L30-A
RM18L30-A
RM24L30-A
SM18L30A-A
SM21L30-B
SM24L30-A
YM18L34-A
9 COMPRESSOR 61716652 1111600
9 COMPRESSOR 61716651 1 1 600
9 COMPRESSOR 61716663 1 1 1 600
9 COMPRESSOR 61716664 1 600
9 COMPRESSOR 61716660 1 600
10 EVAPORATOR COIL 61850011 1 1 1 400
10 EVAPORATOR COIL 61850002 1 400
10 EVAPORATOR COIL 62050017 1 1 1 1 1 400
10 EVAPORATOR COIL 62050016 1 1 400
11 CONDENSER COIL 62050215 1 1 1 1 1 400
11 CONDENSER COIL 61850200 1111 1 410
11 CONDENSER COIL 61850205 1 410
* DRIER, LIQUID 60308101 1 1111111 480
DRIER/CK.VALVE/CAP TUBE 92500000 1 471
* REVERSING VALVE 25018701 1 500
* CAPILLARY TUBE 01389975 1 1 1 471
* CAPILLARY TUBE 03760479 1 1 1 471
* CAPILLARY TUBE 03760452 3333471
