Installation of hot and cold water supply line valves
For 3/8 plumbing For 1/2 plumbing
Hand tighten brass nuts then apply 1/4 turn with a wrench.
1/2"M X 3/8"F X 1/4"Comp.
with needle valve
RO Tubes will be connected on page 6.
Step 6 Turn off the hot and cold water supply to the faucet by turning the angle stop valves off.
Step 7 Remove water supply line at faucet to the angle stop valves.
Step 8 Attach the water supply line valves as illustrated in the drawings above.
Step 9 Re -attach the water supply line to the fittings attached to the angle stop valves.
5
To RO System
1/4" Compression Nut
Plastic Sleeve
Brass Insert
Angle Stop Valve
(not included)
1/4" Compression Nut
Plastic Sleeve Brass
Insert
3/8"M X 1/2"F
Adapter Angle Stop Valve
Rubber (notincluded)
Washer
