Technical description and specifications.
Before mounting or replacing accessories, pull the plug.
This preventive safety
measure rules out the danger of injuries through accidental starting of the vac-
uum cleaner.
Your vacuum cleaner may include only a part of the accessories described or shown in this
instruction manual.
Type Turbo I Turbo II Turbo III
Reference number 9 20 24 9 20 25 9 20 26
Power input 1000 W 1050 W 1200 W
Max. connected load of the integrated socket
outlet 1800 W 1800 W 1800 W
Power supply type 1 ~ 1 ~ 1 ~
Container volume 24 l 35 l 55 l
Air flow 3200 l/min 3200 l/min 3500 l/min
Max. pressure difference 230 mbar 230 mbar 250 mbar
Weight according to
EPTA-Procedure 01/2003 9.8 kg 10.5 kg 11.6 kg
Class of protection I I I
WARNING
Fig. 1
Hose connection
socket
Air-flow regulator
Casters
On/Off switch
Integrated socket
outlet
Handle
Cord holder
Fastener
