Circle the model of your cooler and record the
serial number below.
Read Carefully All Of This Manual Before
Installing The Unit.
Read And Save These Instructions
Serial #
Encierre con un circulo el modelo de su enfriador y
escribe el número de serie abajo.
Lea Con Cuidado Todo Este Manual Antes De Instalar
La Unidad.Número De Serie
Table Of Contents
Safety Instructions .............................................................................2
Operation ............................................................................................2
Installation Instructions ...................................................................2-3
Maintenance Section ..........................................................................3
Troubleshooting .................................................................................4
Warranty ............................................................................................. 4
Electrical Wiring Diagrams ................................................................5
General Specifi cations .......................................................................6
Parts List - Wet Section (All models) .............................................6-7
Parts List - Blower Section (AD100B, AD150B, AD200B) ..............8
Parts List - Blower Section (AS100B, AS150B, AS200B) ................9
Parts List - Blower Section (AU200B) ............................................10
Parts List - Blower Section (Single Inlet Coolers) ...........................11
Motor Specifi cations ........................................................................12
Pulley and Belt Kit Specifi cations ...................................................12
Spanish (Instrucciones en Español) ............................................ 13-16
Models
(Double Inlet)
AD100, AS100, AD10012, AS10012
AD150, AS150, AD15012, AS15012
AD20012, AS20012, AU20012
(Single Inlet)
SAD100, SAS100, SAD10012, SAS10012
SAD150, SAS150, SAD15012, SAS15012
110526 2-09
Vea el Español en el interior.
The New Industrial
