Appendix C: Technical Specifications
Computer Video Port Pin Assignments
The Computer port is a female video RGB, 15-pin micro-D-style
connector. Here are its pin assignments:
Pin no. Computer port
1 Red video
2Green video
3 Blue video
4 Monitor (ID bit 2)
5 GND
6 Red video GND
7 Green video GND
8 Blue video GND
9+5 V
10 Synchronous GND
11 Monitor (ID bit 0)
12 SDA
13 Horizontal sync
14 Vertical sync
15 Reserved
