Performance Specications
Accuracy
Electrical input to pressure output: ±5% of span
Pressure output to feedback: ±5% of span
Feedback volts to pressure output: ±5% of span
Pulse input to pressure output: ±20% of span
Sensitivity
.04% of span (Min. input for readable output)
Repeatability
±0.5% of span
Environmental Effect
±1% max. full scale per 50ºF (28ºC) change
Supply Voltage Effects
±0.15% max. full scale per 1 volt change
Hysteresis Effect
(Output to Gage) ½% of span
Supply Pressure Effect
0.1 Max. PSI change in output for 10 PSI
change in supply pressure (within supply limits)
Gas/Air Consumption
0.007 SCFM at 40 psig supply pressure, at
steady state and increasing supply pressures.
•
•
•
•
•
•
•
•
•
Environmental Specications
Primary Location
Suitable for eld or housed-in unheated
buildings
Temperature Limits
-20 to 150º F (-29 to 66°C) operating
-40 to 185º F (-40 to 85°C) storage
Humidity Limits
10 to 95% RH, -20 to 130° F, (-29 to 55° C)
operating
10 to 50% RH, 130 to 150°F (55 to 66°C)
operating
Vibration Limits
0.1 g max., 10 – 500 Hz
Interference
R.F.I. rejection of the actuator depends on the
shielding of the input and output since the aluminum
housing (with cover in place) greatly attenuates RF
eld strength.
Effect with wiring enclosed in conduit SAMA STD
PMC 33.1, Class 1 and 2, 20 MHz to 500 MHz:
<0.5% FS error
Case Classication
Designed to NEMA type 4 hazardous
Safety
Designed to meet ANSI Standard C39.5
Explosion-proof for Class 1, Division 1, Groups B,
C and D; Dust-ignition-proof for Class II, Division 1,
Groups E, F and G; Suitable for Class III, Division 1;
Nonincendive for Class 1, Division 2, Groups A, B,
C and D.
•
•
•
•
•
•
•
