EURO 25 -1 31
VENTING OF THE EURO-25-1 INSIDE THE HOST GAS FIREPLACE
A connector kit (BCV4-KIT or BCV5-KIT) is used to connect the EURO 25-1
insert to the host gas fireplace’s venting system. The connector slips into the host
fireplace’s B-vent.
• Follow the connector kit’s instructions in assembling the kit.
• Remove the flue adapter plate from the EURO 25-1 insert and attach the
connector kit to the plate with the sheet metal screws provided.
• Slide the connector into the host gas fireplace’s vent.
• Slide the flue adapter plate onto the EURO 25-1 as it is being inserted into the
host fireplace. Level the EURO 25-1 as described in manual.
• Complete the installation of the surround and accessories as described in the
manual.
• Check for proper venting of the fireplace after installation.
* BCV4-KIT is the connector kit used for host fireplaces with 4” diameter flue
connector and venting system. BCV5-KIT is for host fireplaces with 5”
diameter flue connector and venting system. For venting systems larger than
5” diameter, run 4” diameter flexible aluminum gas liner from the insert
through the host’s venting system to the host fireplace’s vent termination.
Connector Kit
(BCV4-KIT or BCV5-KIT)
Gasket
B-Vent
APPENDIX A
EURO 25-1 - INSTRUCTIONS FOR
INSTALLATION INTO VENTED GAS FIREPLACES
