Operating Instructions
COLORado™ 3P User Manual 18 3/17/2009 9:54 AM
Menu Map
000 ~ 255*
(0 ~ 100%)
*Strobe range
is 0 ~ 20 (000
~ 255)
User can combine Red, Green and Blue
to generate a custom color
Select intensity over pre-composed
colors yellow, cyan, purple and white
Select strobing frequency between 0
and 20Hz
Sets the DMX starting address
To operate with DMX control
To operate with the COLOr-CON
Choose from 8 Automatic run programs
Assigns the ID address to a fixture
Either enables or disables ID addressing
Sets the number of ADAS channels for use
when automating DMX channel assignment
Enables the Automatic DMX512
Addressing System
When activated the DMX512 address
assigned by the ADAS will become
permanent on the fixture
Resets fixture to factory default settings
When password is set to on the control
panel will ask for a password each time the
control panel is accessed
Use UP and DOWN buttons to set and
press SET to confirm
Note! If you forget the password use the
following factory password:
UP, DOWN, UP, DOWN, UP, UP, DOWN,
DOWN
Manual Power ON/OFF
The COLORado™ can be turned on and off using the control panel.
When {MENU} is displayed in the LCD panel, hold down the (EXIT) button for 3
seconds to turn off the fixture.
Hold the {EXIT} button for 3 seconds to turn power on.
