Preparing and Installing the 9A426-02 Module
2-14
Figure 2-10. User-Accessible Components on Underside of Daughterboard
SMB-1 PROM
The 9A426-02 Module is shipped with an SMB-1 Firmware PROM. The SMB-1
Firmware PROM is located on the underside of the module’s daughterboard as
shown in Figure 2-10.
To upgrade the SMB-1 PROM, install the SMB-1 PROM Upgrade Kit. Installation
instructions are included in the upgrade kit.
DIP Switch
BOOT PROM
SMB-1 PROM
DRAM SIMM slot
FLASH SIMM slot
