REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
31M700
K Included in Engine Gasket Set−Ref. No.358.
D Included in Carburetor Overhaul Kit−Ref. No. 121 or 121A.
z Included in Carburetor Gasket Set−Ref. No. 977.
∆ Included in Valve Gasket Set−Ref. No 1095.
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
5643−9 Assemblies include all parts shown in frames. 03/13/2007
9
127 695005 Plug−Welch
127A D690727 Plug−Welch
130 691750 Valve−Throttle
130A 699500 Valve−Throttle
131 790901 Kit−Throttle Shaft
131A 699501 Kit−Throttle Shaft
133 494381 Float−Carburetor
133A 694914 Float−Carburetor
135 698780 Tube−Fuel Transfer
(Nikki)(Gravity Feed)
−−−−−− Note −−−−−−
792022 Tube−Fuel
Transfer
(Nikki)(Pump Feed)
137D
z281165s Gasket−Float Bowl
137A D698781 Gasket−Float Bowl
141 790902 Kit−Choke Shaft
141B 695420 Kit−Choke Shaft
142 D697140 Nozzle−Carburetor
(Standard)
146 691639 Key−Timing
187B 791805 Line−Fuel
(Formed)(10−1/4
Inches Long)(Cut to
Required Length)
188 691693 Screw
(Control Bracket)
192 691986 Adjuster−Rocker Arm
202 691841 Link−Mechanical
Governor
209 692208 Spring−Governor
−−−−−− Note −−−−−−
790602 Spring−
Governor
Used on Type No(s).
0112.
216 691840 Link−Choke
222 694042 Bracket−Control
227 691374 Lever−Governor
Control
232 691842 Spring−Governor Link
238 691843 Cap−Valve
240 394358s Filter−Fuel
(White, 75 Microns)
Used on Type No(s).
0101, 0215, 0234,
0237.
240B 695666 Filter−Fuel
(Includes 30 Micron
Paper Element)
Used on Type No(s).
0111, 0112, 0167.
265 691024 Clamp−Casing
267 695134 Screw
(Casing Clamp)
−−−−−− Note −−−−−−
690804 Screw
(Casing Clamp)
Used on Type No(s).
0101, 0111, 0112.
268 691025 Casing−Control Wire
(Cut To Required
Length)
269 691026 Wire−Control
(Cut To Required
Length)
270 691027 Nut
(Control Wire Casing)
271 691028 Lever−Control
276 D
z692255 Washer−Sealing
276A 695410 Washer−Sealing
300 697349 Muffler
Used on Type No(s).
0111.
300A 698356 Muffler
Used on Type No(s).
0112.
304 790009 Housing−Blower
(Black)
305 697102 Screw
(Blower Housing)
305A 697103 Screw
(Blower Housing)
306 697107 Shield−Cylinder
307 691003 Screw
(Cylinder Shield)
309 693551 Motor−Starter
310 690323 Screw
(Starter Motor)
311 497608 Brush Set
333 492341 Armature−Magneto
334 691061 Screw
(Magneto Armature)
337 491055s Plug−Spark
Used on Type No(s).
0101, 0112, 0215,
0234.
−−−−−− Note −−−−−−
691043 Plug−Spark
Used on Type No(s).
0167, 0237.
344 693675 Screw
(Cable Clamp)
356 697089 Wire−Stop
Used on Type No(s).
0101, 0111, 0167,
0237.
358 794150 Gasket Set−Engine
363 19203 Puller−Flywheel
383 89838s Wrench−Spark Plug
385 694476 Screw
(Fuel Pump)
Used on Type No(s).
0111, 0112, 0167.
385A 690297 Screw
(Fuel Pump)
Used on Type No(s).
0111, 0112, 0167.
387 697090 Pump−Fuel
Used on Type No(s).
0111, 0112, 0167.
387A 808656 Pump−Fuel
Used on Type No(s).
0111, 0112, 0167.
404 691691
Washer
(Governor Crank)
415 690283 Plug
(Engine Sump)
431 697122 Elbow−Intake
445 697153 Filter−Air Cleaner
Cartridge
(Washable)
462 691261 Washer
(Starter Cable)
474A 696459 Alternator
(Dual Circuit)
Used on Type No(s).
0215, 0234.
474B 696457 Alternator
(Tri Circuit)
Used on Type No(s).
0101, 0112, 0237.
474C 696458 Alternator
(10 Amp Circuit)
Used on Type No(s).
0111, 0167.
480 693675 Screw
(Tube Clamp)
