AXIS P1343-E Network Camera
Technical Specifications
Function/group
Item
Specifications
Operating
conditions
Temperature:-30ºCto50ºC(-22ºFto122ºF)withPoE;downto-40ºC(-40ºF)with
High PoE
Approvals
EN 55022 Class B, EN 55024, EN 60950-1, EN 61000-6-1, EN 61000-6-2
FCC Part 15 Subpart B Class B
ICES-003 Class B
VCCI Class B
C-tick AS/NZS CISPR 22
EN 50121-4/IEC 62236, EN 60950-22, IEC 60068-2-6, IEC 60068-2-27, IEC 60529 IP66,
NEMA 250 Type 4X, IEC 62262 IK10
Dimensions
(HxWxD)
87/120 x 140/161 x 404 mm (3.4/4.7” x 5.5/6.4” x 15.9”) including sunshield
Weight
3.1 kg (6.8 lb.)
Included
accessories
Stand, connector kit, Installation Guide, CD with installation tools, recording software
and User’s Manual, Windo ws decoder 1-user license
Wall mount bracket, sunshield, cable glands
Video
management
software (not
included)
AXISCameraStation—Videomanagementsoftwareforviewingandrecordingupto50
cameras
See www.axis.com/products/video/software/ for more software applications via partners
Optional
accessories
Various ho u sings, lenses
AXIS T90A Illuminators
AXIS T8412 Installation Display
Axis PoE Midspa n s
AXIS Camera Station and video management software from Axis’ Application
Development Partners
Axis’ Application Development Partners. For more software information, see
www.axis.com/products/video/software/
Performance considerations
When settings up your system, it is import
ant to consider how various settings and situations will affect performance. So m e factors
affect the amount of bandwidth (the bit rate) required , others can affect the frame rate, and some affect both. If the load on the
CPU reache s its maximum, this will also affect the frame rate.
The following factors are among the most important to consider:
• High image resolution and/or lower compression levels result in images containing more data. Bandwidth affected.
• Access by large numbers of Motion JPEG and/or unicast H.264 clients. Bandwidth affected.
• Simultaneous viewing of different streams (resolution, compression) by different clients. Effecton frame rate and bandwidth.
• Accessing Motion JPEG and H.264 video streams simultaneously. Frame rate and bandwidth affected.
• Heavy usage of event settings affect the product’s CPU load. Frame rate affected.
• Heavy network utilization due to poor infrastructure. Bandwidth affected.
• Viewing on poorly performing client computers lowers perceived performance. Frame rate affected.
