Chapter 1 11
Hardware Specifications and Configurations
NOTE:
The BIOS can be overwritten/upgraded using the AFLASH utility (AFLASH.EXE).
Processor
Item Specification
Type AcerPower Sx: Intel Pentium III, Celeron or Cyrix III processor
AcerPower Sc: Intel Tualatin Pentium III, Celeron processor
Socket 370
Speed AcerPower Sx: 500/550/600 MHz, 533/667/733 MHz
AcerPower Sc: Coppermine up to 1.1 GHz
Tualatin from 1.2 to 1.4 GHz and above
Celeron 850/950 MHz , 1.1/1.2 GHz
Minimum operating speed 0 MHz (If
Stop CPU Clock in Sleep State in BIOS Setup
is set to
Enabled
.)
Voltage Processor voltage can be detected by the system without setting any
jumper.
BIOS
Item Specification
BIOS code programmer Acer
BIOS version AcerPower Sx :V4.0, R01-A4
AcerPower Sc : R07-B3
BIOS ROM type Bulk mode flash ROM
BIOS ROM size AcerPower Sx: 256Kbyte
AcerPower Sc: 4MB
BIOS ROM package 32-pin DIP package
Support protocol PCI 2.2, APM1.2, DMI 2.00.1, E-IDE, ACPI 1.0, ESCD 1.03, ANSI
ATA 3.0, PnP 1a, Bootable CD-ROM 1.0, ATAPI
Boot from CD-ROM feature Yes
Support to LS-120 drive No
Support to BIOS boot block feature No
BIOS Hotkey List
Hotkey Function Description
++
Enter BIOS Setup Utility Press while the system is booting to enter
BIOS Setup Utility.
F8 Enable hidden page of BIOS Setup
Utility
Press in BIOS Setup Utility main menu
screen, the Advanced Options menu then
appears.
The items on the Advanced Options menu
are:
Memory/Cache Options
PnP/PCI Options
