365147-YTG-C-0608
6 Johnson Controls Unitary Products
— = Not applicable.
13 SEER HP WITH AV / SV / F*FV - VARIABLE SPEED
THGD18S21S1 AV24 17 – 565 18.0 13.4 14.00 12.00
THGD24S21S1 AV24 17 – 770 23.0 17.5 14.00 12.00
THGD30S21S1 AV36 21 – 1015 29.0 22.0 14.00 12.00
THGD36S21S1
AV36 21 – 1270 35.0 26.2 14.00 12.00
AV/SV48 24 – 1270 35.0 26.2 14.00 12.00
THGD42S21S1
AV/SV48 24 – 1415 41.0 29.4 13.85 11.00
AV/SV60 24 – 1410 41.0 29.4 13.85 11.00
F4FV060 24 – 1410 41.0 29.4 13.85 11.00
THGD48S21S1
AV/SV48 24 – 1610 46.0 33.8 13.25 11.00
AV/SV60 24 – 1655 46.0 33.6 13.25 11.00
F4FV060 24 – 1655 46.0 33.6 13.30 11.00
13 SEER HP WITH AHP / SHP / F*FP
THGD18S21S1
AHP18 17 – 650 18.0 12.9 13.00 11.00
AHP24 17 – 655 18.0 13.0 13.00 11.00
F4FP024 17 – 655 18.0 13.0 13.00 11.00
THGD24S21S1
AHP24 17 – 830 23.0 16.9 13.00 11.00
AHP30 17 – 795 23.0 16.8 13.00 11.00
F4FP030 17 – 795 23.0 16.8 13.00 11.00
THGD30S21S1
AHP30 17 – 1015 29.0 21.2 13.00 11.00
AHP36 21 – 1040 29.0 21.2 13.00 11.00
F4FP040 21 – 1040 29.0 21.2 13.00 11.00
THGD36S21S1
AHP36 21 – 1235 35.0 25.6 13.00 11.00
AHP42 21 – 1255 35.0 25.6 13.00 11.00
AHP/SHP60 24 – 1270 35.0 26.2 14.00 12.00
F4FP045 24 – 1200 35.0 25.6 13.00 11.00
F5FP048 24 – 1200 35.0 26.2 14.00 12.00
F5FP060 24 – 1200 35.0 26.2 14.00 12.00
THGD42S21S1
AHP/SHP48 24 – 1400 40.0 29.0 13.00 11.00
AHP/SHP60 24 – 1400 41.0 29.4 13.85 11.00
F4FP045 24 – 1400 40.0 29.0 13.00 11.00
F5FP048 24 – 1400 41.0 29.4 13.85 11.00
F5FP060 24 – 1400 41.0 29.4 13.85 11.00
THGD48S21S1
AHP/SHP48 24 – 1600 45.0 33.2 13.00 11.00
AHP/SHP60 24 – 1600 46.0 33.6 13.30 11.00
F5FP060 24 – 1600 46.0 33.6 13.30 11.00
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ARI Standards 210.
Cooling MBH based on 80°F entering air temperature, 50% RH, and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTU’s at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTU’s during a normal annual usage period for cooling divided by the total electric power
input in watt-hours during the same period.
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER
COIL
MODEL
1
COOLING
MODEL W
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
