255029-YTG-J-1007
Unitary Products Group 9
ELECTRICAL DATA (FOR MULTI SOURCE POWER SUPPLY) - COPPER WIRE 208/230-1-60
Models
Heater
Models
Min. Circuit Ampacity
Max. O.C.P.
1
Amps/Type
75°C Wire Size - AWG
Circuit Circuit Circuit
1st 2nd 3rd 1st 2nd 3rd 1st 2nd 3rd
208/240 208/240 208/240 208/240 208/240 208/240 208/240 208/240 208/240
AHP24B**(N,H)21 4HK16501306 40.9 / 47.0 19.5 / 22.5 – 45 / 50 20 / 25 – 8 / 8 10 / 10 –
AHP30B**(N,H)21
4HK16501306 41.6 / 47.9 19.5 / 22.5 – 45 / 50 20 / 25 – 8 / 8 10 / 10 –
4HK165N1506 45.8 / 52.8 21.7 / 25.0 – 50 / 60 25 / 25 – 8 / 6 10 / 10 –
AHP36C**(N,H)21
4HK16501506 47.5 / 54.5 21.7 / 25.0 – 50 / 60 25 / 25 – 8 / 6 10 / 10 –
4HK16501806 43.9 / 50.3 39.8 / 45.8 – 45 / 60 40 / 50 – 8 / 6 8 / 8 –
AHP42C**(N,H)21
4HK16501506 47.6 / 54.8 21.7 / 25.0 – 50 / 60 25 / 25 – 8 / 6 10 / 10 –
4HK16501806 44.0 / 50.6 39.8 / 45.8 – 45 / 60 40 / 50 – 8 / 6 8 / 8 –
4HK16502006 47.6 / 54.8 43.4 / 50.0 – 50 / 60 40 / 50 – 8 / 6 8 / 8 –
AHP48D**(N,H)21
SHP48D**N21
4HK16501506 47.6 / 54.8 21.7 / 25.0 – 50 / 60 25 / 25 – 8 / 6 10 / 10 –
4HK16501806 44.0 / 50.6 39.8 / 45.8 – 45 / 60 40 / 50 – 8 / 6 8 / 8 –
4HK16502006 47.6 / 54.8 43.4 / 50.0 – 50 / 60 40 / 50 – 8 / 6 8 / 8 –
AHP60D**(N,H)21
SHP60D**N21
4HK16501506 52.9 / 59.5 21.7 / 25.0 – 60 / 60 25 / 25 – 6 / 6 10 / 10 –
4HK16501806 49.3 / 55.3 39.8 / 45.8 – 50 / 60 45 / 60 – 6 / 6 8 / 6 –
4HK16502006 52.9 / 59.5 43.4 / 50.0 – 60 / 60 45 / 50 – 6 / 6 8 / 8 –
4HK16502506 52.9 / 59.5 43.4 / 50.0 21.68 / 25.00 60 / 60 45 / 50 25 / 25 6 / 6 8 / 8 10 / 10
1. O.C.P. = Over Current Protection device, must be HACR type Circuit Breaker or Time Delay fuse.
ELECTRICAL DATA - 208/230-3-60
Models
Heat Kit -
Three Phase
Max.
Static
Min.
Speed
Tap
Total Heat
1
KW Staging
KW MBH W1 Only W2 Only W1 + W2
208V 240V 208V 240V 208V 240V 208V 240V 208V 240V
AHP24B**(N,H)21 4HK06501025 0.5 Hi 7.2 9.6 24.6 32.8 7.2 9.6 7.2 9.6 7.2 9.6
AHP30B**(N,H)21
4HK06501025 0.5 Hi 7.2 9.6 24.6 32.8 7.2 9.6 7.2 9.6 7.2 9.6
4HK065N1525 0.5 Hi 10.8 14.4 36.9 49.1 10.8 14.4 10.8 14.4 10.8 14.4
AHP36C**(N,H)21
4HK06501025 0.5 Med 7.2 9.6 24.6 32.8 7.2 9.6 7.2 9.6 7.2 9.6
4HK06501525 0.5 Med 10.8 14.4 36.9 49.1 10.8 14.4 10.8 14.4 10.8 14.4
AHP42C**(N,H)21
4HK06501025 0.5 Med 7.2 9.6 24.6 32.8 7.2 9.6 7.2 9.6 7.2 9.6
4HK06501525 0.5 Med 10.8 14.4 36.9 49.1 10.8 14.4 10.8 14.4 10.8 14.4
4HK06501825 0.5 Hi 12.9 17.2 44.7 58.7 12.9 17.2 12.9 17.2 12.9 17.2
AHP48D**(N,H)21
SHP48D**N21
4HK06501025 0.5 Med 7.2 9.6 24.6 32.8 7.2 9.6 7.2 9.6 7.2 9.6
4HK06501525 0.5 Med 10.8 14.4 36.9 49.1 10.8 14.4 10.8 14.4 10.8 14.4
4HK06501825 0.5 Hi 12.9 17.2 44.7 58.7 12.9 17.2 12.9 17.2 12.9 17.2
AHP60D**(N,H)21
SHP60D**N21
4HK06501025 0.5 #3 7.2 9.6 24.6 32.8 7.2 9.6 7.2 9.6 7.2 9.6
4HK06501525 0.5 #4 10.8 14.4 36.9 49.1 10.8 14.4 10.8 14.4 10.8 14.4
4HK16501825 0.5 #4 12.9 17.2 44.7 58.7 12.9 17.2 12.9 17.2 12.9 17.2
4HK16502525 0.5 #4 18.0 24.0 61.4 81.4 9.0 12.0 18.0 24.0 18.0 24.0
1. See conversion table on Page 7.
