NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
REPLACEMENT PARTS LIST
Gas Controls - SIT Millivolt
Item
No.
Description Natural Gas Propane Gas
Part No. Qty. Part No. Qty.
15 Gas Valve, SIT H6209 1 88J53 1
16 Piezo Igniter 10K86 1 10K86 1
--- Piezo Igniter Wire 56L21 1 56L21 1
17 Pilot Assembly 69L17 1 69L18 1
18 Pilot Generator 60J79 1 60J79 1
19 Thermocouple 74L57 1 74L57 1
20 Pilot Tube 74L56 1 74L56 1
21 Electrode and Cable 74L58 1 74L58 1
Gas Controls - Dexen Electronic
Item
No.
Description Natural Gas
Part No. Qty.
28 Gas Valve, Dexen H4681 1
29 Pilot Assembly H4673 1
30 Igniter Module H4674 1
31 Battery Holder H4675 1
32 Wire Harness H4676 1
33 Adaptor H4677 1
Item No. Description SLDVT-30 SLDVT-35 SLDVT-40 SLDVT-45
Part No. Qty. Part No. Qty. Part No. Qty. Part No. Qty.
1 Hood H7568 1 H7266 1 H7267 1 H7569 1
2 Lower Control Compartment Panel H7556 1
H7262
1
H7263
1 H7557 1
3 Enclosure, Glass Front (Complete) H7560 1 H7264 1 H7265 1 H7561 1
4 Door Latch Spring H1264 2 H1264 2 H1264 2 H1264 2
5 Log Set (Complete) H7244 1 H7244 1 H7245 1 H7547 1
6 Burner Assembly H7258 1 H7253 1 H7259 1 H7550 1
7 Orifice, Main Burner - Natural Gas H4873 1
H1355
1 60J80 1 37L70 1
7 Orifice, Main Burner - Propane Gas 35M91 1 75L10 1 99K78 1 99K79 1
8 Bag of Glowing Embers (Rockwool) 88L53 1 88L53 1 88L53 1 88L53 1
8 Bag of Decorative Volcanic Stone 80L42 1 80L42 1 80L42 1 80L42 1
9 Orifice Holder H7257 1 H7257 1 H7257 1 H7257 1
10 Gas Line Flexible Connector 93L32 1 93L32 1 93L32 1 93L32 1
11 Sub-Floor H7558 1 H7450 1 H7462 1 H7741 1
WARNING
Failure to position the parts in accordance with these
diagrams or failure to use only parts specifically
approved with this appliance may result in property
damage or personal injury.
AVERTISSEMENT
Risque de dommages ou de blessures si les pièces
ne sont pas installées conformément à ces schémas
et ou si des pièces autres que celles spécifiquement
approuvées avec cet appareil sont utilisées.
Contact an Authorized Lennox Hearth Products dealer to obtain any of
these parts. Never use substitute materials. Use of non-approved parts
can result in poor performance and safety hazards.
SUPERIOR
®
DIRECT-VENT GAS FIREPLACES • MODELS SLDVT-30/35/40/45 • CARE AND OPERATION INSTRUCTIONS
