O
p
eration - Mechanical Models
1. Power indicator
2. Fan operating indicator
3. Cooling operating indicator
4. Full water indicator
5. Thermostat
6. Speed switch with options for:
LOW FAN, HIGH FAN, LOW
COOL, HIGH COOL
7. Timer (1-8 hours) as well as
ON/OFF switch
W
A-1010M
1. Control Panel
2. Cooling Air Outlet
3. Handle
4. Castors
5. Air Filter
6. Air Inlet
7. Exhaust Air Outlet
8. Cord Hanger
9. Water Stopper (Rubber Plug Inside)
Turning ON/OFF
Set TIMER to ON for continuous operation (the unit will operate as long as it is not
turned off). Power indicator comes on.
To turn off the unit, turn the TIMER to the OFF position.
Accessories
10. Adaptor - for insertion over the hose and
into the back of the air conditioner.
11. Exhaust Hose
Length: 14”-60”
Diameter: 4.75”
12. Foam Strip - for filling the open window
space and with a hole for connection to th
exhaust hose.
13. Foam Strip - for filling the open window
space.
14. Round Connector - to be used between
hose and window kit or between hose and
wall.
15. Cap for Round Connector
16. Remote Control
(Electronic control models only)
Setting Function
/
Ventilation Speed
WA-1010M
Turn the speed switch to select the required setting:
LOW FAN, HIGH FAN, LOW COOL, HIGH COOL,
SPEED OFF
5
10
5
1 2
3
4
7
6
1
2
3
4
5
6
7
8
9
High Cool
Low Cool
SPEE
Low Fan
High Fan
Dimension:7”x24.5x.75”
Dimension:7”x24.5x.75”
