INSTALLING THE PUMP HOSE
Step 2: Remove the pump hose connector from the top
of the bucket. It is located to the left of the bucket han-
dle. (Fig. 9)
Step 3: Thread the pump hose connector onto the
drain nozzle that is visible after removing the bucket.
(Fig. 10)
(FIG. 8)
(FIG. 9)
(FIG. 10)
OPTION 3: USING THE INTERNAL VERTICAL PUMP - Only install when us-
ing pump mode!
INSTALLING THE INTERNAL PUMP HOSE
Step 1: Remove the bucket from the dehumidifier (Fig.
8)
11
INSTALLING THE PUMP HOSE
Step 4: Insert the pump hose onto the pump hose con-
nector. Push the clamp towards the connector to se-
cure the connection. (Fig. 11).
(FIG. 11)
Step 5: Remove the drain cover from the back of the
bucket prior to seating the bucket in the unit. (Fig. 12)
Place bucket in the dehumidifier for use (Fig.13)
(FIG. 12)
(FIG. 13)
NOTE: When removing the drain hose, excess water may spill from the
dehumidifier. Use a small pan or bowl to catch the water and prevent it
from spilling onto the unit or the floor.
