FILTERS
Motor filter
The motor filter must be
cleaned everytime the bag is
changed to remove the fine dust
particles collected. This can be
done by shaking it.
However, after approximately 5
dustbag changes, the filter
should be replaced.
The motor filter is found in the
dustbag removed, remove the
filter grill, press the centre tab
and pull out G. Pull out the
filter H, shake to clean and
replace. The grill must be
replaced after the filter has been
cleaned.
Exhaust filter
The exhaust filter must be
cleaned everytime the bag is
changed to remove the time fine
dust particles collected. This
can be done by shaking it.
However, after approximately 5
dustbag changes, the filter
should be replaced.
The exhaust filter is located
behind the exhaust filter cover
Á. To remove, unclip the cover
and remove the filter I and
clean and replace.
HINTS & TIPS
Cleaning and
maintenance
Your cleaner is manufactured to
withstand normal day-to-day
use, but as occasional wipe
over will help maintain its good
looks. Abrasive cleaners should
not be used.
Purchasing dustbags
replacement filters
Use only Morphy Richards
replacement dustbags and
filters which can be purchased
from specialist retailers or by
calling the number on the front
page of this leaflet.
Vacuum freshener
(certain models only)
1 After emptying the dust bag and
removing the filters (as
described in points 1-4 above)
open the clear packaging and
remove the vacuum freshener.
2 Place it directly into the dust
bag as shown J.
3 Refit the filters (as described in
point 5 above).
Only place the vacuum
freshener directly into the dust
bag. Do not place in the filter or
any other part of your vacuum
cleaner.
New vacuum fresheners can be
purchased from Morphy
Richards on Replacement parts
telephone line.
HELPLINE
If you have any difficulty with
your appliance, do not hesitate
to call us.
We are more likely to be able to
help than the store from where
you bought it.
Please have the following
information ready to enable our
staff to deal with your query
quickly.
• Name of the product
• Model number as shown on the
underside of the appliance.
• Serial number as shown on
underside of the appliance.
UK Helpline 0870 060 2604
Replacement Parts 0870 1676635
Ireland Helpline 1800 409119
H
G
UUKK HHeellpplliinnee 00887700 006600 226600 RReeppllaacceemmeenntt PPaarrttss 00887700 116677 66663355 IIrreellaanndd HHeellpplliinnee 11880000 440099111199
I
J
