5
4 The arrow on the
collar of the dust
bagmust point
downwards when
fitting.
Note: The dustbag compartment lid
will not close unless the dustbag is fitted
correctly.
IMPORTANT
• All filters should be checked
regularly for signs of damage,
preferably after each cleaning task.
The filters must be replaced
immediately if they become
damaged.
• Always disconnect the cleaner from
the mains when checking filters or
replacing dust bag.
• Always make sure the dust bag, grill
andfilters are fitted before use.
Failure to do so may result in damage
to your product.
Motor filter
The motor filter must be cleaned
everytime the bag is changed to remove
the fine dust particles collected. This can
be done by shaking it.
However, after approximately 5
dustbag changes, the filter should be
replaced.
The motor filter is
found in the dustbag
compartment. With the
dustbag removed
remove the filter
grill, press the
centre tab and
pull out. Pull out
the filter, shake to
clean and
replace.
The grill must be replaced after the
filter has been cleaned.
Replacing the dustbag
To obtain the best results from your
cleaner be sure to check and change the
dustbag regularly, otherwise the airflow
and cleaning power of your cleaner will
be reduced and you may damage your
cleaner.
Dustbag condition indicatorDustbag condition indicator
Dustbag condition indicatorDustbag condition indicator
Dustbag condition indicator
If the suction power decreases or if the
dustbag condition indicator shows
fully red then the bag must be emptied
immediately and/or the motor protection
filter cleaned, even if the bag does not
appear full. This will also occur if the
nozzle, tubes or hose have become
blocked.
• The dustbag indicator may
occasionally show red during
use - this is quite normal.
1 Lift the dust compartment lid
.
2 Pull the dustbag retaining clip forward
to release. Carefully lift the dustbag
clear of the cleaner and dispose of the
dustbag.
3 To fit the new dustbag first locate the
bottom end of the dustbag collar into
the guide slot at the bottom of the
dustbag compartment then pull the
collar forward until it locates into the
securing clip.
