6 UK Helpline 0870 060 2604 Replacement Parts 0870 167 6635 Ireland Helpline 1800 409119
6
3 Fit the new replacement allergy
filter.
4 Refit the grille.
Dispose of the used allergy filter
in the dust bin.
Cleaning the dust
canister filter
1 Operate the filter cleaning
clicker lever fl several times
and empty the canister over a
bin and then close the canister.
2 To access the filter assembly
rotate the dust canister lid ˜
anti clockwise and remove from
the dust canister J.
3 Turn the central mesh filter ı
clockwise to remove and clean
as required K.
4 Detach the pleated circular filter
Ù from the canister lid ˜ by a
firm pull action L.
5 Both the mesh and pleated
filters may be washed (in warm
water only) but must be
thoroughly air-dried before re-
fitting.
The spare pleated filter allows
one filter to be washed and
dried whilst the other is in use.
6 Re-locate the pleated filter back
into position on the canister lid
by aligning the tabs on the dust
canister lid ˜ (marked by
arrows) L with cut away
sections on the top of the
pleated filter before pushing into
place.
Refit the mesh filter and turn
anti-clockwise to lock into
position on the dust canister lid.
Re-attach the canister lid on to
the canister by aligning the
arrows on the canister lid and
the canister J. Then rotating
the canister lid clockwise.
J
K
L
˜
Ù
73352 rev2 22/6/06 11:09 Page 6
