I
SpEcIFIcATIONS
I - 1
Note: All weights were made on prototype vehicles. Your production trailer may vary slightly. More information on weighing and loading your trailer can be found under “Weight
Rating” in the forward section of this manual. Information pertaining to your trailer can be found in your vehicle on the back of the wardrobe door about 60” up from the floor. The
Unit Base Weight (UBW) and the Net Carrying Capacity (NCC) is not the same as the Unloaded Vehicle Weight (UVW) and the Cargo Carrying Capacity (CCC) shown on the Trailer
Weight Information tag in your vehicle. The UBW and NCC weights are for the base unit with no options and fluids. The UVW and CCC on the Trailer Weight Information tag are
weights for the individual vehicle as built with its options and certain water capacities.
SpEcIFIcATIONS 16 19 20 22 23 25 FB 25 A/B 25 SS 28 W 28 SO 30
Length - Exterior 16’ 7” 19’2” 20’10” 22’4” 23’ 25’ 11” 25’ 11” 25’11” 27’11” 28’11” 30’10”
Width - Exterior 8’ 8’ 8’ 8’ 8’ 8’ 8’ 5 ½” 8’ 5 ½” 8’ 5 ½” 8’5 ½” 8’5 ½”
Width-Interior 7’ 7” 7’7” 7’7” 7’ 7” 7’ 7” 8’ 1” 8’1” 8’1” 8’1” 8’1” 8’1”
Height-Ext. w/ A/C 9’ 4” 9’5” 9’5” 9’ 4” 9’ 5” 9’ 7” 9’7” 9’7” 9’7” 9’7” 9’7”
Height-Int. w/ A/C 6’ 4.5” 6’ 4.5” 6’ 4.5” 6’ 4.5”” 6’ 5” 6’ 5” 6’ 5” 6’ 5” 6’ 5” 6’ ” 6’ 5”
*Hitch ball Height 18” 17 ¼” 17 ¼” 18 ” 17 ¾” 17 ¾” 17 ¾” 17 ¾” 17 ¾” 17 ¾” 17 ¾”
Hitch Wt. (Dry, no
options)
390 480 600 510 600 720 860 750 830 1,010 850
GVWR (lbs.) 3500 4500 5000 5600 6000 7300 7000 7300 7300 9100 8400
UBW (lbs.) 2,950 3680 3965 4160 4500 5210 5065 5380 5495 6515 6215
NCC (lbs.) 550 820 1035 1440 1500 2090 1935 1920 1805 2585 2185
Fresh Water (Gal) 23 23 23 30 30 39 39 39 39 54 39
Gray Water (Gal)
Combo
21
21 21 21 21 37 39 39 37 37 39
Black Water (Gal.) 18 18 21 18 39 33 18 35 39 18
Tire Size
ST215/
75R14
ST225/
75RI5
ST225/
75RI5
ST215/
75R14
ST225/
75RI
ST225/
75RI5
ST225/
75RI5
ST225/
75RI5
ST225/
75RI5
ST225/
75RI5
ST225/
75RI5
Tire Inflation (PSI) Cold
ST 205-75 R14 - 50 psi ST 225-75 R15 - 65 psi
