LENNOX HEARTH PRODUCTS
KITS AND ACCESSORIES
775,169M
REV. B 06/2006
INSTALLATION INSTRUCTIONS FOR OPTIONAL STYLE VIEW DOOR KITS
FOR USE WITH GAS FIREPLACES
STYLE VIEW DOOR KITS - CHARCOAL,
TEXTURED IRON, SATIN PEWTER & ANTIQUE BRASS
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Page 1 of 2
ARCH DESIGN KITS
Cat. No. Model Description Model Series
H0858 AD35C 35” Arch Doors, Charcoal
MPD3530
MPD35ST
MPB35ST
LMDV-3530
H0859 AD35TI 35” Arch Doors, Textured Iron
H0860 AD35SP 35” Arch Doors, Satin Pewter
H0861 AD35AB 35” Arch Doors, Antique Brass
H0862 AD40C 40” Arch Doors, Charcoal SDDV-40, EDV4035,
ED4035-2,
*EDVST, EDST-2,
EDVCR/L, EDCR/L-2,
EDVPF, EDPF-2,
MPD4035, LMDV-4035
H0863 AD40TI 40” Arch Doors, Textured Iron
H0864 AD40SP 40” Arch Doors, Satin Pewter
H0865 AD40AB 40” Arch Doors, Antique Brass
H0866 AD45C 45” Arch Doors, Charcoal
EDV4540, ED4540-2,
MPD4540
H0867 AD45TI 45” Arch Doors, Textured Iron
H0868 AD45SP 45” Arch Doors, Satin Pewter
H0869 AD45AB 45” Arch Doors, Antique Brass
H0870 AD35EC 35” Elite Arch Doors, Charcoal
SDDV-35, EDV3530,
ED3530
H0871 AD35ETI 35” Elite Arch Doors, Textured Iron
H0872 AD35ESP 35” Elite Arch Doors, Satin Pewter
H0873 AD35EAB 35” Elite Arch Doors, Antique Brass
ARCH PANE DESIGN KITS
H0930 APD35C 35” Arch Pane Doors, Charcoal
MPD3530
MPD35ST
MPB35ST
LMDV-3530
H0931 APD35TI 35” Arch Pane Doors, Textured Iron
H0932 APD35SP 35” Arch Pane Doors, Satin Pewter
H0933 APD35AB 35” Arch Pane Doors, Antique Brass
H0934 APD40C 40” Arch Pane Doors, Charcoal SDDV-40, EDV4035,
ED4035-2,
* EDVST, EDST-2,
EDVCR/L, EDCR/L-2,
EDVPF, EDPF-2,
MPD4035, LMDV-4035
H0935 APD40TI 40” Arch Pane Doors, Textured Iron
H0936 APD40SP 40” Arch Pane Doors, Satin Pewter
H0937 APD40AB 40” Arch Pane Doors, Antique Brass
H0938 APD45C 45” Arch Pane Doors, Charcoal
EDV4540, ED4540-2,
MPD4540
H0939 APD45TI 45” Arch Pane Doors, Textured Iron
H0940 APD45SP 45” Arch Pane Doors, Satin Pewter
H0941 APD45AB 45” Arch Pane Doors, Antique Brass
H0942 APD35EC 35” Elite Arch Pane Doors, Charcoal
SDDV-35, EDV3530,
ED3530
H0943 APD35ETI 35” Elite Arch Pane Doors, Textured Iron
H0944 APD35ESP 35” Elite Arch Pane Doors, Satin Pewter
H0945 APD35EAB 35” Elite Arch Pane Doors, Antique Brass
SQUARE DESIGN KITS
H0946 SD35C 35” Sq. Doors, Charcoal
MPD3530
MPD35ST
MPB35ST
LMDV-3530
H0947 SD35TI 35” Sq. Doors, Textured Iron
H0948 SD35SP 35” Sq. Doors, Satin Pewter
H0949 SD35AB 35” Sq. Doors, Antique Brass
SQUARE DESIGN KITS (continued)
Cat. No. Model Description Model Series
H0950 SD40C 40” Sq. Doors, Charcoal SDDV-40, EDV4035,
ED4035-2,
*EDVST, EDST-2,
EDVCR/L, EDCR/L-2,
EDVPF, EDPF-2,
MPD-4035, LMDV-4035
H0951 SD40TI 40” Sq. Doors, Textured Iron
H0952 SD40SP 40” Sq. Doors, Satin Pewter
H0953 SD40AB 40” Sq. Doors, Antique Brass
H0954 SD45C 45” Sq. Doors, Charcoal
EDV4540, ED4540-2,
MPD4540
H0955 SD45TI 45” Sq. Doors, Textured Iron
H0956 SD45SP 45” Sq. Doors, Satin Pewter
H0957 SD45AB 45” Sq. Doors, Antique Brass
H0958 SD35EC 35” Elite Sq. Doors, Charcoal
SDDV-35, EDV3530,
ED3530
H0959 SD35ETI 35” Elite Sq. Doors, Textured Iron
H0960 SD35ESP 35” Elite Sq. Doors, Satin Pewter
H0961 SD35EAB 35” Elite Sq. Doors, Antique Brass
SQUARE PANE DESIGN KITS
H0962 SPD35C 35” Sq. Pane Doors, Charcoal
MPD3530
MPD35ST
MPB35ST
LMDV-3530
H0963 SPD35TI 35” Sq. Pane Doors, Textured Iron
H0964 SPD35SP 35” Sq. Pane Doors, Satin Pewter
H0965 SPD35AB 35” Sq. Pane Doors, Antique Brass
H0966 SPD40C 40” Sq. Pane Doors, Charcoal SDDV-40, EDV4035,
ED4035-2,
*EDVST, EDST-2,
EDVCR/L, EDCR/L-2,
EDVPF, EDPF-2,
MPD-4035, LMDV-4035
H0967 SPD40TI 40” Sq. Pane Doors, Textured Iron
H0968 SPD40SP 40” Sq. Pane Doors, Satin Pewter
H0969 SPD40AB 40” Sq. Pane Doors, Antique Brass
H0970 SPD45C 45” Sq. Pane Doors, Charcoal
EDV4540, ED4540-2,
MPD4540
H0971 SPD45TI 45” Sq. Pane Doors, Textured Iron
H0972 SPD45SP 45” Sq. Pane Doors, Satin Pewter
H0973 SPD45AB 45” Sq. Pane Doors, Antique Brass
H0974 SPD35EC 35” Elite Sq. Pane Doors, Charcoal
SDDV-35, EDV3530,
ED3530
H0975 SPD35ETI 35” Elite Sq. Pane Doors, Text. Iron
H0976 SPD35ESP 35” Elite Sq. Pane Doors, Satin Pewt.
H0977 SPD35EAB 35” Elite Sq. Pane Doors, Ant. Brass
KIT CONTENTS: TOOLS REQUIRED:
1 ea. Door, Left
1 ea. Door, Right
1 ea. Doorframe Assembly
1 ea. Instruction Sheet
None
Arch Design
Arch Pane Design
Square Pane Design
Square Design
* Note: EDVST models manuafactured August 2004 or earlier
will also require a magnet mounting kit, Cat. No. H2110
