6
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
General Information
The fireplace models covered in this manual
are direct-vent sealed combustion gas fireplace
heaters designed for residential application.
These direct-vent appliances operate with the
combustion chamber completely isolated from
the indoor environment.
All air for combustion is brought in from the
outside and exhaust gases are vented through
the same direct-vent, co-axial (intake/exhaust)
vent system.
The Millivolt appliances have a millivolt gas
control valve with piezo ignition system. If any
optional accessories which require electrical
power are being installed, the electrical power
must be provided at the time of appliance in-
stallation.
The Electronic appliances have a battery backed-
up electronic intermittent pilot system. No
external electrical power is required to operate
these appliances.
These appliances comply with National Safety
Standards and are tested and listed by OMNI-Test
Laboratories, Inc. (Report No. 116-F-39C-5)
to ANSI ZZ21.88 (in Canada, CSA-2.33), and
CAN/CGA-2.17-M91 in both USA and Canada,
as vented gas fireplace heaters.
The Installation must conform to local codes
or, in the absence of local codes, with the
National Fuel Gas Code, ANSI Z223.1/NFPA
54-latest edition, or the Natural Gas and Propane
Installation Code, CAN/CSA B149.1-latest edi-
tion. The appliance, when installed, must be
electrically grounded in accordance with local
codes or, in the absence of local codes, the
latest edition of the National Electrical Code,
ANSI/NFPA 70, or the Canadian Electrical Code,
CSA C22.1 - latest editions.
The vent termination is hot while in opera-
tion and for a period of time following the
use of the fireplace. To prevent contact
with hot surfaces, we recommend the use
of a termination guard. See Page 21 for
ordering information.
These fireplaces are designed as supple-
mental heaters. Therefore, it is advisable
to have an alternate primary heat source
when installed in a dwelling.
These appliances must not be connected to
a chimney or flue serving a separate solid
fuel burning appliance.
INSTALLATION, SERVICE,
AND MAINTENANCE
IMPORTANT: Improper installation,
adjustment, alteration, service, or
maintenance can cause injury or
property damage. Refer to this manual.
For assistance or additional information,
consult a qualified installer, service
agency or the gas supplier.
Only trim kit(s) supplied by the
manufacturer shall be used in the
installation of this appliance.
Draft relief openings must not be
covered or blocked.
These appliances must not be
connected to a chimney or flue serving a
separate solid fuel burning appliance.
Any change to this appliance and/or
its operating controls is dangerous.
Improper installation or use of this
appliance can cause serious injury or
death from fire, burns, explosion or
carbon monoxide poisoning.
Carbon Monoxide Poisoning: Early
signs of carbon monoxide poisoning
are similar to the flu with headaches,
dizziness and/or nausea. If you
have these signs, obtain fresh air
immediately. Turn off the gas supply to
the appliance and have it serviced by
a qualified professional, as it may not
be operating correctly. Some people
are more affected by carbon monoxide
than others, including pregnant women,
people with heart or lung disease or
anemia, those under the influence of
alcohol, and those at high altitudes.
Turn off gas and electrical power to the
fireplace and allow it to cool before
cleaning or servicing the appliance.
OPERATION
Do not operate appliance with the glass
front removed, cracked, or broken.
These fireplaces are vented gas
appliances. Do not burn wood or other
material in these appliances.
This appliance is only for use with the
type of gas indicated on rating plate.
This appliance is not convertible for use
with other gases, unless a certified kit is
used.
These appliances are designed to
operate on natural gas or propane
gas only. The use of other fuels or
combinations of fuels will degrade the
performance of this system and may be
dangerous.
Provide adequate clearances around
air openings and adequate accessibility
clearance for service and proper
operation. Never obstruct the front
openings of the appliance.
Do not use this appliance if any part has
been under water. Immediately call a
qualified service technician to inspect the
appliance and to replace any part of the
control system and any gas control that
has been under water.
WARRANTY
Failure to comply with the installation
and operating instructions provided
will result in an improperly installed
and operating appliance, voiding its
warranty.
Do not attempt to alter or modify the
construction of the appliance or its
components. Any modification or
alteration may void the warranty,
certification, and listings of this unit.
