GENERAL INFORMATION
HORIZONTAL TERMINATION
SHROUD KIT
The horizontal Termination Shroud Kit may be used as a decorative cover
for the square termination and to minimize exposure to the hot surface
of the termination.
This kit contains one termination shroud kit and these instructions.
HEARTH PRODUCTS
KITS AND ACCESSORIES
INSTALLATION INSTRUCTIONS FOR THE HORIZONTAL TERMINATION SHROUD KIT
(MODEL NUMBER 4.5HTSK) (CATALOG NUMBER H5820) FOR USE WITH SQUARE TERMINATIONS
WHICH MAY BE USED WITH DIRECT VENT GAS FIREPLACES
INSTALLATION INSTRUCTIONS
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Note - Shroud kit installation does not require the removal of the
square termination.
Step 1.
Turn off the fireplace and allow the termination to cool before
proceeding.
Step 2. Loosen the four (4) screws on the existing square termination
(refer to Figure 1 ).
Step 3. Slide the body of the shroud over the termination screws that
have been loosened, setting it in place (refer to Figure 1 ).
P/N 750,246M
REV. B 04/2008
WARNING: THIS KIT MUST BE INSTALLED BY A QUALI-
FIED SERVICE TECHNICIAN OR OTHER QUALIFIED
AGENCY ACCORDING TO THE MANUFACTURER’S
INSTRUCTIONS, ALL CODES AND REQUIREMENTS OF
THE AUTHORITY HAVING jURISDICTION IN THE USA OR
CANADA. THE QUALIFIED AGENCY PERFORMING THIS
WORK ASSUMES RESPONSIBILITY FOR THIS INSTAL-
LATION.
WARNING: THE SHROUD KIT PROVIDES PROTECTION
FROM THE HIGH TEMPERATURES OF THE TERMINATION
ExCEPT AT THE TOP PORTION OF THE SHROUD KIT. THIS
AREA IS ExTREMELY HOT DUE TO THE DISCHARGING
FLUE GASES.
US
