Page 2 For technical questions, please call 1-800-520-0882. ITEM 69774
Table of Contents
Specifications ............................................. 2
Safety ......................................................... 4
Setup .......................................................... 6
Operation ................................................... 10
Maintenance .............................................. 13
Troubleshooting ......................................... 17
Warranties ................................................. 20
Parts Lists and Diagrams .......................... 22
Specifications
Pump
Suction & Discharge Size 2" NPT
Discharge Capacity 151 GPM
Maximum Discharge Head 97.5 ft.
Maximum Suction Head 26 ft.
Maximum Pressure 42.2 PSI
Mechanical Seal Ceramic
Included Accessories Intake Strainer, Hose Clamps, Spark Plug Wrench
Engine
Displacement 212cc
Engine Type
Horizontal Single Cylinder 4 stroke OHV
EPA phase III compliant
Cooling System Forced air cooled
Fuel
Type 87+ octane unleaded gasoline
Capacity 0.9 Gallons / 3.6 Liters
Engine Oil
Type SAE
10W‑30 above 32° F
5W30 at 32° F or below
Capacity 0.5 Quarts / 0.5 Liters
Run Time @ 50% Load with full tank 3 hr.
Sound Level at 22 feet 104 dB
Bore x Stroke 70 mm x 55 mm
Compression Ratio 8.5:1
Rotation viewed from PTO
(power takeoff ‑ the output shaft)
Counterclockwise
Shaft
Shaft 3/4" x 2.41"
Keyway 3/16" (4.76 mm)
End Tapped 5/16" ‑ 24 UNF
Spark Plug
Type
NGK
®
BP‑6ES
NHSP
®
/ Torch
®
F6TC
Gap 0.7 ‑ 0.8 mm
Valve Clearance
Intake 0.10 ‑ 0.15 mm
Exhaust 0.15 ‑ 0.20 mm
No Load Speed 3,800 ±100 RPM
Discharge Head (ft.)
PERFORMANCE CURVE
Flow (Gallons/minute)
SAFETY OPERATION MAINTENANCESETUP
