Page 18

For Pump technical questions, please call 1-800-444-3353. Item 68375

For Engine technical questions, please call 1-800-520-0882.

Parts List (Including Item 68120 212cc engine)

Part Description Qty

1 Cylinder Head Gasket 1

2 Cylinder Head Cover

Subassembly

1

3 Cylinder Head

Cover Gasket

1

4 Breather Tube 1

5 Bolt 4

6 Stud 1

7 Stud 1

8 Stud 2

9 Pin 2

10 Cylinder Head Bolt 4

11 Spark Plug 1

12 Cylinder Head

Subassembly

1

13 Crankcase

Subassembly

1

14 Engine Oil Sensor 1

15 Governor Gear Assy. 1

16 Governor Arm 1

17 Drain Plug Bolt 2

18 Washer 2

19 Bearing 1

20 Oil Seal 1

21 Washer 1

22 Pin 1

23 Bolt 2

24 Crankcase Cover 1

25 Bearing 1

26 Oil Seal 1

27 Crankcase Gasket 1

28 Pin 2

29 Oil Dipstick

Subassembly

1

30 Engine Oil Plug

Subassembly

1

31 Bolt 6

32 Crankshaft Assy. 1

33 Piston Pin Clip 2

34 Piston 1

35 Piston Pin 1

36 Connecting Rod 1

37 First Ring 1

38 Second Ring 1

39 Oil Ring Set 1

40 Camshaft Assy. 1

41 Exhaust Valve 1

42 Intake Valve 1

43 Valve Spring Seat 1

Part Description Qty

44 Retainer Exhaust Valve 1

45 Rotator Valve 1

46 Seal Guide 1

47 Valve Tappet 2

48 Valve Lifter 2

49 Lifter Stopper Plate

Subassembly

1

50 Valve Adjusting Bolt 2

51 Valve Rocker 2

52 Valve Adjusting Nut 2

53 Valve Lock Nut 2

54 Valve Spring 2

55 Recoil Starter Assy. 1

56 Bolt 3

57 Shroud 1

58 Cylinder Body Shroud 1

59 Lower Shield 1

60 Oil Protector 1

61 Engine Switch

Subassembly

1

62 Bolt 2

63 Bolt 1

64 Collar 1

65 Bolt 1

66 Bolt 4

67 Carburetor Assy. 1

68 Air Cleaner Gasket 1

69 Carburetor Gasket 1

70 Carburetor

Insulator Plate

1

71 Carburetor

Insulator Gasket

1

72 Nut 2

73 Air Cleaner 1

74 Exhaust Outlet Gasket 1

75 Nut 2

76 MuferAssy. 1

77 Fuel Tank 1

78 Fuel Filter 1

79 Fuel Tank Cover 1

80 Fuel Tank Oil Outlet

Subassembly

1

81 Collar 2

82 Fuel Tube 1

83 Bolt 1

84 Nut 2

85 Flywheel Nut 1

86 Starter Pulley 1

87 Impeller 1

88 Flywheel Subassembly 1

Part Description Qty

89 Bolt 2

90 Ignition Coil 1

91 Throttle Control Assy. 1

92 Bolt 2

93 Governor Spring 1

94 Governor Rod 1

95 Throttle Valve

Returning Spring

1

96 Governor Support Bolt 1

97 Nut 1

98 Governor Support

Subassembly

1

99 Hose Clamp 3

100 Filter Cover 1

101 Filter 1

102 Bolt 11

103 Washer 7

104 Washer 4

105 Water Inlet 1

106 Gasket Inlet Water 1

107 Thread Plug 2

108 Screw Plug Washer 2

109 Outlet Water 1

110 Gasket Outlet 1

111 Pump Body 1

112 Ring Whorl Case

Sealing

1

113 Whorl Case 1

114 Bolt 1

115 Washer 1

116 Water Pump Impeller 1

117 Key 1

118 Water Pump

Joint Cushion

1

119 Impeller Seal Ring 1

120 Porcelain Seal 1

121 Seal Assy. Mechanism 1

122 Water Pump Joint 1

123 Washer 4

124 Bolt 4

125 Water Pump Assy. 1

126 Engine Frame Assy. 1

127 Bolt 4

128 Engine Frame Shock

Absorption Seat

4

129 Core Nut 4

130 Bolt 4

131 Nut 4

132 Rubber Jacket 1
