Pump
Suction & Discharge Size 1-1/2" NPT
Discharge Capacity 75 GPM
Maximum Discharge Head 79 ft.
Maximum Suction Head 26 ft.
Maximum Pressure 34.2 PSI
Mechanical Seal Ceramic
Included Accessories
Intake Strainer
Hose Clamps
Spark Plug Wrench
Engine
Displacement 99cc
Engine Type Horizontal Single Cylinder 4 stroke OHV
Cooling System Forced air cooled
Fuel
Type 87+ octane unleaded gasoline
Capacity 0.5 Gallons / 2 Liters
Engine Oil
Type SAE
10W-30 above 32° F
5W30 at 32° F or below
Capacity 0.37 Quarts / 0.35 Liters
Run Time @ 50% Load
with full tank
3 hr.
Sound Level at 22 feet 100 dB
Bore x Stroke 56 mm x 40 mm
Compression Ratio 8.5:1
Rotation viewed from PTO
(power takeoff - the output shaft)
Counterclockwise
Shaft M16 x 1.5 (Outside thread)
Spark Plug
Type Torch
®
E7TC
Gap 0.7 - 0.8 mm
Valve Clearance
Intake 0.10 - 0.15 mm
Exhaust 0.15 - 0.20 mm
No Load Speed 3,800 RPM±100RPM
Specications
Flow (Gallons/minute)
Discharge Head (ft.)
