Performance certified is for installation Type B - free inlet, ducted outlet. Power rating (Bhp) does not include transmission losses. Performance ratings do not include the
effects of appurtenances (accessories). The AMCA Certified Ratings Seal applies to air performance only.
SWB-106 - Belt Drive
Series 100
26
5
⁄8
(676)
12 (305)
16
7
⁄8 (429)
1
1
⁄2
(38)
11
1
⁄2
(292)
15
1
⁄8
(384)
11
1
⁄4
(286)
18
3
⁄4
(476)
22
1
⁄4
(565)
16 (406)
21
7
⁄8 (556)
23
1
⁄2 (597)
15
1
⁄2
(394)
9
3
⁄4
(248)
11
(279)
8
5
⁄8
(219)
2
(51)
Wheel Diameter = 11
1
⁄8 (283)
Shaft Diameter = 3/4 (19)
Outlet Area = 0.76 ft
2
(0.07 m
2
)
^Approximate Unit Weight = 135 lb. (61 kg)
All dimensions in inches (millimeters)
For additional discharge positions see page 13
^Weight shown is largest cataloged Open Drip Proof motor
CFM OV
Static Pressure in Inches wg
0.25 0.5 0.75 1 1.25 1.5 1.75 2 2.25 2.5
100 132
RPM 936 1273 1542
BHP 0.02 0.04 0.06
Sones 5.4 6.8 8.0
140 184
RPM 1023 1322 1574 1799 1999 2179
BHP 0.02 0.04 0.07 0.11 0.14 0.18
Sones 6.0 7.1 8.4 9.8 11.5 13.1
180 237
RPM 1172 1398 1632 1843 2031 2210 2376 2531 2676 2813
BHP 0.03 0.05 0.08 0.12 0.16 0.20 0.24 0.29 0.34 0.39
Sones 6.6 7.5 8.9 10.2 11.9 13.4 14.8 16.3 17.9 19.4
220 289
RPM 1356 1522 1712 1906 2088 2257 2413 2561 2706 2844
BHP 0.05 0.07 0.10 0.13 0.17 0.22 0.26 0.31 0.37 0.42
Sones 7.2 8.2 9.4 10.9 12.6 13.9 15.2 16.7 18.3 19.8
260 342
RPM 1550 1681 1830 1993 2155 2318 2470 2614 2751 2880
BHP 0.07 0.09 0.12 0.15 0.19 0.24 0.29 0.34 0.39 0.45
Sones 8.0 9.0 10.2 11.8 13.2 14.5 15.9 17.4 18.8 20
300 395
RPM 1749 1866 1976 2113 2253 2391 2537 2676 2808 2936
BHP 0.09 0.12 0.15 0.18 0.22 0.27 0.32 0.37 0.42 0.48
Sones 9.1 10.1 11.3 12.8 14.0 15.2 16.6 18.0 19.5 21
340 447
RPM 1952 2056 2158 2258 2379 2500 2626 2745 2876 3000
BHP 0.13 0.15 0.19 0.22 0.26 0.31 0.35 0.41 0.46 0.52
Sones 10.5 11.5 12.5 13.7 14.9 16.2 17.5 18.7 20 22
380 500
RPM 2156 2253 2344 2434 2524 2633 2736 2852 2963
BHP 0.17 0.20 0.23 0.27 0.31 0.35 0.40 0.45 0.51
Sones 12.2 12.8 13.7 14.7 16.2 17.4 18.6 19.9 21
420 553
RPM 2361 2452 2535 2618 2699 2779 2879 2973
BHP 0.23 0.26 0.29 0.33 0.37 0.42 0.46 0.51
Sones 14.7 14.2 15.1 16.1 17.2 18.8 20 21
460 605
RPM 2567 2654 2732 2806 2883 2956
BHP 0.29 0.32 0.36 0.40 0.44 0.49
Sones 17.9 16.2 16.9 17.8 18.9 19.8
500 658
RPM 2775 2858 2931
BHP 0.37 0.40 0.44
Sones 22 22 18.9
Static Pressure (in. wg)
Volume (cfm)
Volume (m
3
/hr)
Static Pressure (Pa x 100)
0 200 400 600 800 1000
0
1
2
3
4
5
6
7
8
D
o
n
o
t
s
e
l
e
c
t
t
o
t
h
e
l
e
f
t
o
f
t
h
i
s
s
y
s
t
e
m
c
u
r
v
e
0 100 200 300 400 500 600
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
670 670
1135 1135
1600 1600
2065 2065
2530 2530
3000 3000
½ ½
¼ ¼
SWB-106
RPM
HP
Density 0.075 lb/ft
3
3
Maximum BHP at a given RPM = (RPM/3706)
3
(Maximum KW at a given RPM = (RPM/4086)
3
)
Maximum RPM = 3000
Tip Speed (ft/min.) = RPM x 2.91
(Tip Speed (m/s) = RPM x 0.0148)
Maximum Motor Frame Size = 145T
SWB-106
