SSX16
HigH-EfficiEncy, 2- to 5-ton
Split SyStEm Air conditionEr
Up to 16 SEEr
Standard Features
• R-410Achlorine-freerefrigerant
• High-efciencyCopeland®scrollcompressor
• High-qualitycompressorsoundblanket
• High-pressureswitch;low-pressureswitch
• Factory-installedlterdrier
• 850RPMcondenserfanmotor
• Coppertube/enhancedaluminumncoil
• Sweatconnectionservicevalves
witheasyaccesstogaugeports
• Contactorwithlugconnection
• Groundlugconnection
• AHRICertied;ETLListed
Cabinet Features
• Goodman®brandsoundcontroltopdesign
• Steellouvercoilguard
• Heavy-gaugegalvanized-steelcabinet
• AttractiveArchitecturalGraypowder-paint
nishwith500-hoursalt-sprayapproval
• Topandsidecompressorandtubingaccess
• Single-panelaccesstocontrolswithspace
providedforeld-installedaccessories
• Whenproperlyanchored,meets2001FloridaBuild-
ingCodeunitintegrityrequirementsforhurricane-
typewinds(Anchorbracketkitsavailable.)
cooling cApAcity:
24,000 to 57,000 BtU/H
Contents
Nomenclature....................................... 2
ProductSpecications.......................... 3
ExpandedCoolingData........................ 4
AHRIRatings........................................ 22
WiringDiagrams................................. 54
Dimensions.........................................56
Accessories.......................................... 56
*Completewarrantydetailsavailablefromyourlocaldealeroratwww.goodmanmfg.com.ToreceivetheLifetimeCompressorLimited
Warranty(goodforaslongasyouownyourhome)andthe10-YearPartsLimitedWarranty,onlineregistrationmustbecompletedwithin
60daysofinstallation.OnlineregistrationisnotrequiredinCaliforniaorQuebec.
