Coil/Cabinet Top/Side Panels
Ref.
No:
Part
No:
Description:
Ref.
No:
Part
No:
Description:
Image 1:
TOP PANEL 26" (M1, M2, M3)0121R00008PDG11
TOP PANEL 29" (M4, M5, M6, M7, M8, M9, M10,
M11, M12, M13, M14, M15, M16, M17, M18)
0121R00010PDG11
TOP PANEL 35" (M19, M20, M21, M22, M23, M24)0121R00012PDG11
COND MOTOR 1/4 HP, 1 SP, 6 PL (M5, M11, M14,
M16)
0131M00007PS21
COND MOTOR 1/4 HP, 1 SP, 6 PL (M13)0131M00018PS21
COND MOTOR 1/4 HP, 1 SP, 8 PL (M15, M17)0131M00014PS21
COND MOTOR 1/4 HP, 8 PL, 460V (M18)0131M00022S21
COND MOTOR 1/6 HP, 1 SP, 8 PL (M19, M20, M21,
M22)
0131M00012PS21
COND MOTOR 1/6 HP, 1 SP, 8 PL (M1, M2, M3,
M4, M6, M7, M8, M9, M10, M12)
0131M00060S21
COND MOTOR 1/6 HP, 8 PL, 460V (M23, M24)0131M00023S21
ACORN NUT 5/16 HEX BLACK (QTY 4)0163M00006P41
FAN BLADE 20" (M1, M3)0150M00018S51
FAN BLADE 20" CCW (M2)0150M00012S51
FAN BLADE 22" (M5, M11)0150M00007S51
FAN BLADE 22" (M13, M14, M16)B1086775S51
FAN BLADE 22" TNT2203-25 (M4, M6, M7, M8, M9,
M10, M12, M18)
0150M00008S51
FAN BLADE 26" ALUM CCW (M19, M20, M21, M22,
M23, M24)
10625738S51
FAN BLADE TYPE 3 (M15, M17)B1086765S51
VENTURI RING 22" (M14, M15, M16, M17, M18)0161L0000061
VENTURI RING 35" (M19, M20, M21, M22, M23,
M24)
0161R00007P61
LOUVERED SIDE PANEL (M1)0121R00014PDGB111
LOUVERED SIDE PANEL (M3)0121R00016PDGB111
LOUVERED SIDE PANEL (M6, M7, M8, M11, M12,
M13)
0121R00025PDGB111
LOUVERED SIDE PANEL (M4, M5, M9, M10)0121R00026PDGB111
LOUVERED SIDE PANEL (M2)0121R00102PDGB111
LOUVERED SIDE PANEL-VERTICAL (M14, M15,
M16, M17, M18)
0121R00027PDGB111
LOUVERED SIDE PANEL-VERTICAL (M19, M20,
M21, M22, M23, M24)
0121R00043PDGB111
LOUVERED SIDE PANEL (M1)0121R00017PDGB121
LOUVERED SIDE PANEL (M3)0121R00019PDGB121
LOUVERED SIDE PANEL (M6, M7, M8, M11, M12,
M13)
0121R00031PDGB121
LOUVERED SIDE PANEL (M4, M5, M9, M10)0121R00032PDGB121
LOUVERED SIDE PANEL (M2)0121R00109PDGB121
LOUVERED SIDE PANEL-VERTICAL (M14, M15,
M16, M17, M18)
0121R00033PDGB121
LOUVERED SIDE PANEL-VERTICAL (M19, M20,
M21, M22, M23, M24)
0121R00047PDGB121
LOUVERED SIDE PANEL (M1)0121R00020PDG131
LOUVERED SIDE PANEL (M3)0121R00022PDG131
Image 1:
LOUVERED SIDE PANEL (M6, M7, M8, M11, M12,
M13)
0121R00037PDG131
LOUVERED SIDE PANEL (M4, M5, M9, M10)0121R00038PDG131
LOUVERED SIDE PANEL (M2)0121R00116S131
LOUVERED SIDE PANEL-VERTICAL (M14, M15,
M16, M17, M18)
0121R00039PDG131
LOUVERED SIDE PANEL-VERTICAL (M19, M20,
M21, M22, M23, M24)
0121R00051PDG131
TUBING ASSY, COND COIL (M2)0201R00177S141
TUBING ASSY, COND COIL (M1)1362100141
TUBING ASSY, COND COIL (M3)1362101141
TUBING ASSY, COND COIL (M4, M5, M9, M10)1362103141
TUBING ASSY, COND COIL (M6, M7, M8, M11,
M12, M13)
1362104141
TUBING ASSY, COND COIL (M14, M15, M16, M17,
M18)
1362105141
TUBING ASSY, COND COIL (M19, M20, M21, M22,
M23, M24)
1362106141
CONDUIT (M1, M2, M3)0161R00001PNS
CONDUIT (M14, M15, M16, M17, M18)0161R00002PNS
CONDUIT (M4, M5, M6, M7, M8, M9, M10, M11,
M12, M13)
0161R00003PNS
CONDUIT (M19, M20, M21, M22, M23, M24)0161R00004PNS
Expanded Model Nomenclature
M1 - GSC130181AB
M2 - GSC130181CA
M3 - GSC130241AB
M4 - GSC130301AB
M5 - GSC130361BB
M6 - GSC130361DA
M7 - GSC130361DB
M8 - GSC130361DF
M9 - GSC130361EA
M10 - GSC130361EB
M11 - GSC130363AB
M12 - GSC130363AC
M13 - GSC130421AB
M14 - GSC130481AB
M15 - GSC130481AC
M16 - GSC130483AB
M17 - GSC130483AC
M18 - GSC130484AB
M19 - GSC130601BB
M20 - GSC130601BC
M21 - GSC130603AB
M22 - GSC130603AC
M23 - GSC130604AB
M24 - GSC130604AC
