Unit Assembly
Ref.
No:
Part
No:
Description:
Ref.
No:
Part
No:
Description:
Image 1:
WRAPPER (M1)1721122PDG11
WRAPPER (M2, M3)1721123PDG11
PAINTED UPPER TIE PLATE (M1)0121A00114PDG21
PAINTED UPPER TIE PLATE (M2, M3)0121A00115PDG21
LOWER ACCESS PNL, W/PAINT (M1)0121A00117PDG31
LOWER ACCESS PNL, W/PAINT (M2, M3)0121A00118PDG31
LOWER SERVICE PANEL (M1)1722080PDG41
LOWER SERVICE PANEL (M2, M3)1722081PDG41
UPPER ACCESS PANEL (M1)1722083PDG51
UPPER ACCESS PANEL (M2, M3)1722084PDG51
FILTER COVER LRG (M2, M3)1722087PDG61
FILTER COVER MED (M1)1722086PDG61
BLOWER BLOCK-OFF 10 X 10 (M2, M3)764741F81
BLOWER CUT-OFF (M1)764734F81
BLOWER HOUSING 9 X 8 (M1)1439392S91
BLOWER HOUSING ASSY (M2, M3)0271A00016S91
BLOWER MOUNTING ANGLE (M1)0121A00027101
BLOWER MOUNTING ANGLE (M1)1717109111
BLOWER WHEEL 10 X 10 (M2, M3)B1368048S121
BLOWER WHEEL 9 X 8 (M1)B1368037S121
TRANSFORMER 208/230, 24V B1141643131
MOTOR 1/2 HP, SERIAL ECM (M1)0131M00111S141
MOTOR, 1HP SERIAL ECM (M3)0131M00113S141
MOTOR, 3/4 HP SERIAL ECM (M2)0131M00112S141
WIRE ASSY, 9-PIN MALE CONNECTOR 0259A00002P151
MOTOR CONTROL HARNESS 0259A00009161
PCB, CONTROL, AIR HANDLER PCBJA101S171
PLASTIC DRAIN PAN (HORIZONTAL) (M1)B1756022L211
PLASTIC DRAIN PAN (HORIZONTAL) (M2, M3)B1756028L211
PLASTIC DRAIN PAN (VERTICAL) (M1)B1756017L221
PLASTIC DRAIN PAN (VERTICAL) (M2, M3)B1756020L221
Coil Tubing Assy (M1)0270A00491241
COIL TUBING ASSY (M2)0270A00498241
COIL TUBING ASSY (M3)0270A00499
241
PLASTIC CIRCUIT BREAKER INSERT B1392641251
CIRCUIT BREAKER INSERT GASKET B13926122271
MOTOR MOUNT ARM (M2, M3)B1376853281
MOTOR MOUNT ARM (M1)B1376861281
MOTOR MOUNT BAND 0121M00038291
90 DEGREE STUB BT1369063NS
BOTTOM BRACKET, LARGE (AR) (M2, M3)1721921NS
BOTTOM BRACKET, MEDIUM (AR) (M1)1721920NS
BOTTOM TIE LRG (M2, M3)1721918NS
BOTTOM TIE MED (M1)1721917NS
Image 1:
CAP W/O-RING B9102097NS
FLOWRATOR W/BRACKET, ALUMINUM (M3)0162A00047NS
FLOWRATOR W/BRACKET, ALUMINUM (M1, M2)0162A00050NS
PLASTIC DRAIN COVER (QTY 2)B1392640NS
VALVE CORE BT1787000NS
VALVE, TXV R-410A (M1)0151R00019NS
VALVE, TXV R-410A (M2)0151R00020NS
VALVE, TXV R-410A (M3)0151R00021NS
WIRE HARNESS 0259A00011NS
Expanded Model Nomenclature
M1 - AVPTC183014AA
M2 - AVPTC313714AA
M3 - AVPTC426014AA
