Your opener can be activated via any of the following,
depending on which accessories your opener system has:
■ Remote Control Transmitter
■ Wall Control Panel
■ Doorbell-Type Pushbutton
■ Keyless Entry (optional accessory p.28)
REMOTE CONTROL TRANSMITTER:
■ To open or close garage door, press and hold button
(Midi transmitter has an indicator light that will start
blinking). See Fig. 51A. When garage door begins to
move, release button.
■ To stop garage door during travel, press and hold button
until door stops, then release button.
■ To resume garage door travel after stopping it, press
and hold button until door begins to move, then
release button.
WALL CONTROL PANEL:
■ The illuminated Door Pushbutton will light when properly
connected (if it does not light up, review section 8-11.
“Install Wall Control” on page 14 or refer to “Having a
Problem” on page 29).
■ To open or close garage door, press and hold Illuminated
Door Pushbutton. See Fig. 51B. When garage door begins
to move, release button.
■ To stop garage door during travel, press and hold button
until door stops, then release button.
■ To resume garage door travel after stopping it, press
and hold button until door begins to move, then
release button.
■ The Light On/Off button can be used to turn lights on
or off. Press light On/Off button until lights come on or
turn off. Release button. When using the light On/Off
button, the automatic timer is ignored, and the lights will
remain on until the button is pressed again, or until the
opener is activated and the automatic timer begins again.
■ The Lock/Vacation button can be used to lock out all
remote control transmitters. The door can still be acti-
vated by wall control panel or keyless entry system.
Press and hold Lock/Vacation button for 2-3 seconds.
Release button. Illuminated Door Pushbuttonwill flash
continuously while lock mode is active. To unlock opener,
press and hold Lock/Vacation button for 2-3 seconds.
DOORBELL-TYPE PUSHBUTTON:
■ To open or close garage door, press and hold Pushbutton.
See Fig. 51C. When garage door begins to move, release
button.
■ To stop garage door during travel, press and hold button
until door stops, then release button.
■ To resume garage door travel after stopping it, press
and hold button until door begins to move, then
release button.
OPENER LIGHTS:
■ Lights will come on whenever opener is activated.
Lights will stay on for 4 minutes and 15 seconds, or until
the Light On/Off button on the wall control panel is
pressed, whichever is sooner.
■ Lights can be turned on and off manually as described
under operation of wall control panel.
■ Lights will flash when the opener senses an obstruction
either detected by the internal safety system or the photo
eye. To stop lights from flashing, remove obstruction and
operate door normally.
11. OPERATION OF YOUR OPENER
23
Lock/Vacation
Button
Light On/Off
Button
Illuminated
Door Pushbutton
B. Wall Control Panel
C. Doorbell-Type Pushbutton
Pushbutton
Indicator Light
Buttons
A. 2-Channel Midi Transmitter
Fig. 51
Before you can use your car’s HomeLink
®
device to open a
garage door you must transfer an active code from the
transmitter to the HomeLink
®
Universal Transceiver.
(Reference - HomeLink
®
Manual)
12. HOMELINK
®
TRANSCEIVER
