PTAC Model Number Identification Guide
Model Number T H C 07 K 25 ST C
Series Engineering Code
T = T Series A - B - C
Unit Type Option
E = Electric Heat/No Heat ST = Standard Unit
H = Heat Pump RT = Remote Thermostat
Design Series DC = Central Desk Control
C = Friedrich Manufactured SP = Seacoast Protection
A & B = ICP Manufactured
Nominal Heater Size
Nominal Cooling Capacity (@ 230V or 265V)
07 = 6,500 - 7,200 BTUh 12 = 11,500 - 12,200 BTUh 00 = No electric heater
09 = 8,500 - 9,200 BTUh 15 = 14,000 - 15,000 BTUh 25 = 2.5 KW
34 = 3.4 KW
Voltage 50 = 5.0 KW
K = 208/230V - 1PH - 60Hz R = 265V - 1PH - 60Hz
Notes & Comments
Note Units Affected Note or Comment
Heat Pump All Identifies the parts or components used specifically in the heat
THC units pump units. All other components are consistent with all other
units.
Note 1 Identifies the parts or components used specifically in units built
A, B & C suffix
prior to August 1997 (serial prefix JGHP.....)
Note 2 All Identifies the parts or components used specifically in units built
C suffix only starting September 1997 (serial prefix JGJP.....) to current.
Note 3 All The thermostat was changed from the original that had a short
A & B suffix only 3/8” diameter bulb to the thermostat that has a long 1/4” bulb.
Both have the same operating range. If changing from the 3/8”
bulb this kit is required.
265V All Identifies the parts or components used specifically in units built
Voltage code R to operate on 265V 1PH 60Hz (same as 277V 1PH 60Hz)
Serial Number JG A P 00000
Production Run Number
Year Manufactured
A = 1 D = 4 G = 7 K = 0
B = 2 E = 5 H = 8 Manufacturing Location
C = 3 F = 6 J = 9 S = San Antonio
Month Manufactured P = San Antonio
A = Jan D = Apr G = Jul K = Oct
B = Feb E = May H = Aug L = Nov
C = Mar F = Jun J = Sep M = Dec
PTAC Serial Number Identification Guide
