ARCHITECTURAL AND ENGINEERING SPEC
INSTALLATION OF ALARM
The smoke alarm shall be a First Alert Model SA710B (carbon zinc battery) or SA710AB
(alkaline battery) and shall provide at a minimum the following features and functions:
1. A Photoelectric smoke sensing chamber.
2. The unit shall be capable of self restoring.
3. Fully screened sensing chamber to resist entry of small insects
thereby reducing the probability of unwanted alarms.
4. Powered by a supervised 9V (alkaline cat. no. SA710AB) battery and a solid state
piezo horn rated at 85dB at 10 ft.
5. A visual red LED power-on indicator to confirm unit is receiving power or
is in alarm.
6. A full function test button should check all alarm functions by simulating a smoke
condition, causing the unit to alarm.
7. Silence feature - Temporarily silence unwanted nuisance alarms.
9. Optipath 360 Technology - provides 360 degrees of direct access to the
smoke sensing chambers.
10. Two Locking features - tamper resistant locking pins that lock battery drawer
and/or alarm to mounting bracket.
11. The unit shall be capable of operating between 40°F (4°C) and
100°F (38°C) and relative humidity between 10% and 90%.
12. The unit shall contain mounting hardware and shall be listed for wall
or ceiling mounting.
13. The unit shall at a minimum meet the requirements of UL217, CSFM,
NFPA 72, NFPA 101, ICC
SHIPPING SPECS:
TECHNICAL SPECS
Individual Carton Dimensions 5.125 ”L x 2.380”W x 5.125”H
Weight 0.53lbs.
Cube 0.036 ft3
UPC SA710B: 0 29054 65660 5
SA710AB: 0 29054 00285 3
Master Carton Dimensions 10.630”L x 7.880”W x 10.880”H
Master Pack 12
Weight 7.3lbs.
Cube 0.527 ft3
I2 of 5 SA710B: 100 29054 65660 2
SA710AB: 100 29054 00285 0
Pallet Information
Cases per Layer 22
Number of Layers 4
Cases per Pallet 88
Units per Pallet 1,056
Cube 53.9 ft3
Weight 707 lbs.
Alarm Dimensions: 5.0” dia x 2.1”H
Weight: 8.0 oz.
Operating Voltage: 9V Battery Powered (SA710AB: Alkaline Battery)
Temperature Range: 40°F (4°C) to 100°F (38°C)
Humidity Range: 10% to 90% relative humidity (RH)
Audio Alarm: 85dB at 10 feet
Test/Silence: Electronically simulates smoke condition,
causing the unit to alarm
Manual: Press and hold test/silence button
Alarm Reset: Automatic when smoke clears
Smoke Sensor: Photoelectric
Indicator Lights/Sounds:
DC Power: Intermittent Red Light
Alarm: Audio alarm, rapidly flashing red light
Listing: Listed to UL217 Standard
©2009 BRK Brands, Inc. a Jarden Corporation
Company (NYSE: JAH)
3901 Liberty Street Road
Aurora, IL 60504-8122
All rights reserved
First Alert is a registered trademark of the First Alert Trust
BRK is a registered trademark of BRK Brands, Inc.
CM2950
5.0"
TOP VIEW SIDE VIEW
2.1"
CAT.
SA710B/AB
THE PARTS OF THIS SMOKE ALARM
BOTTOM OF ALARM
1. Mounting bracket
2. Mounting Slots
3. Battery Drawer - Install
9V battery here
4. Turn this way to
remove from bracket
5. Turn this way to
attach to bracket
TOP OF ALARM
1. Test/Silence button
2. Slide-open
battery drawer
3. Red Alarm Light
BATTERY DRAWER LOCK
Remove Pin from
Mounting Bracket
Close Door. Insert Pin in Holes
through alarm and Battery Drawer
MOUNTING
BRACKET
Installation of this smoke alarm must conform to NFPA 72. Always check your local
building codes. Follow all instructions for placement as outlined in the user’s manual.
