620515, 620525, 620526, 630515 & 630516 Installation Instructions
3
620515.331 13,500 1530 12.4 60.0 3.5 10.0 335 / 250 .012 / 0.65 16.5 20 Am p 95 3.5 KW/5.0 KW
620515.336 13,500 1530 12.4 60.0 3.5 10.0 335 / 250 .012 / 0.65 16.5 20 Am p 95 3.5 KW/5.0 KW
620525.331 13,500 1530 12.4 60.0 3.5 10.0 335 / 250 .012 / 0.65 16.5 20 Am p 95 3.5 KW/5.0 KW
620525.336 13,500 12.4 60.0 3.5 10.0 335 / 250 .012 / 0.65 16.5 20 Amp 95 3.5 KW/5.0 KW
620526.331 15,000 12.0 64.0 3.3 8.2 380 / 250 .012 / 0.65 20.0 20 Am p 95 3.5 KW/5.0 KW
620526.336 15,000 12.0 64.0 3.3 8.2 380 / 250 .012 / 0.65 20.0 20 Am p 95 3.5 KW/5.0 KW
630515.331 13,500 12.4 60.0 3.5 10.0 335 / 250 .012 / 0.65 23.5 20 Amp 95 3.5 KW/5.0 KW
630515.336 13,500 12.4 60.0 3.5 10.0 335 / 250 .012 / 0.65 23.5 20 Amp 95 3.5 KW/5.0 KW
630516.331 15,000 12.0 64.0 3.3 8.5 335 / 250 .012 / 0.65 20.0 20 Am p 95 3.5 KW/5.0 KW
630516.336 15,000 12.0 64.0 3.3 8.5 335 / 250 .012 / 0.65 20.0 20 Am p 95 3.5 KW/5.0 KW
SPECIFICATIONS
* For wire length over 24 ft., consult the National Electric Code for proper sizing.
** Dometic Corporation gives GENERAL guidelines for generator requirements. These guidelines come from experiences people have had in actual applications.
When sizing the generator, the total power usage of your recreational vehicle must be considered. Keep in mind generators lose power at high altitudes
and from lack of maintenance.
*** CIRCUIT PROTECTION: Time Delay Fuse or HACR Circuit Breakers Required.
Model
No.
Nominal
Capacity
(BTU/HR)
Cooling
Electrical
Rating
Amps
Heater
Watts
Compressor
Rated
Load
Amps
Compressor
Locked
Rotor
Amps
Fan Motor
Locked
Rotor
Amps
Fan Motor
Rated
Load
Amps
SCFM-High
Speed
Max./Min.
W.C.
Total
Static
Max./Min.
Refrigerant
R-22
(Oz.)
Minimum
Wire Size*
AC Circuit
Protection
** User
Supplied
Installed
Weight
(Pounds)
Minimun
Generator
Size**
1Unit/2Units
120VAC
60Hz.
1 Phase
12 AWG
Copper
Up To 24'
