Architectural Dimming CRESTRON GREEN LIGHT™
Save Override Settings
The state of each output can be saved as an override setting, which can be automatically recalled when the Override
mode is enabled.
NOTE: The control system program has a setting that can prevent locally saving the override state. If this setting is
enabled, the display shows “Er” when trying to save override states. For more information, refer to the SIMPL
Windows help file.
To save the state of all of the outputs as an override setting, press and hold the OVR button for three seconds. The
OVR LED blinks to indicate the new override settings have been stored.
System Operation and Commissioning
This cabinet has been designed as a component of a programmed Crestron system. System commissioning by an
authorized Crestron representative
must be performed to ensure system operation.
Once the cabinet has been wired and the modules have been tested, contact Crestron at 1-888-CRESTRON
[1-888-273-7876] to schedule commissioning.
12 • CRESTRON GREEN LIGHT Architectural Dimming Installation Guide – DOC. 6688A
