Thank you for purchasing this Black&Decker
®
Vacuum Cleaner.
Your new vacuum cleaner comes with two efficient filters that trap dust particles,
and dirt as you vacuum. The permanent dust bag is reusable so you will never have
to buy costly disposable paper replacements.
UNPACKING BOX CONTENTS
After you unpack your unit, identify the following parts (A):
1. Flexible swivel hose
2. Vacuum canister
3. Sweeper
4. 2 extension metal tubes
5. Crevice tool
6. Dusting brush
ᕡ
ᕥ
ᕢ
ᕣ
ᕤ
ᕦ
Product may vary slightly from what is illustrated.
GETTING FAMILIAR WITH YOUR UNIT
A
ᕢ
ᕥ
ᕣ
µ
ᕩ
ᕤ
ᕨ
¸
¹
Ƹ
ƹ
ƺ
ƻ
ᕦ
ᕧ
ᕡ
B
†1.Extension tubes
Chrome tube (Part # VC2500-39E)
Chrome tube with storage
(Part # VC2500-39)
2. Vacuum suction control
†3.Flexible swivel hose w/swivel
connector (Part # VC2500-23)
4. Flexible swivel hose release switch
5. Dust bag "full" indicator
6. Carry handle
7. Retractable cord push button
†8.Exhaust filter cover
(Part #VC2500-11)
†9.Exhaust filter (inside)
(Part #VC2500-12)
10. Retractable cord
†11. Large wheels (1 each)
(Part # VC2500-21)
†12. Motor (not shown)
(Part #VC2500-120V-19)
(Part #VC2500-220V-19)
13. On/Off (I) push button
†14. Dusting brush (Part #VC2500-41)
†15. Crevice tool (Part #VC2500-40)
†16. Sweeper (Part #VC2500-25)
17. Sweeping flaps
18. Lint strips
19. Wheels
† Consumer replaceable
ƽ
Ƽ
ƾ
