REMOVING THE DUST BOWL AND FILTERS (figures E, F, & G)
WARNING: The filters are re-usable and
should be cleaned regularly.
• Press the release latch and pull the dust bowl
straight off as shown in figure E.
• While holding the dust bowl over a bin or sink,
pull out the filter to empty the contents of the
bowl.
•
To replace the dust bowl, place it back onto the
handle until it “clicks” firmly into position.
WARNING: Never use the appliance
without the filters. Optimum dust collection will
only be achieved with clean filters.
PRE-FILTER (figure F)
The Pre filter and Pre Filter Housing can be
separated to allow better cleaning.
• Twist the Pre Filter (F1) in a clockwise direction
and lift from the Pre Filter Housing (F2)
QUICK CLEAN FILTER (figure G)
• Lift the filter cleaning handle.
• While holding the quick clean filter housing
(G1), turn the filter cleaning handle (G2) to
perform a quick clean of the filter.
• Pull the filter out of the quick clean filter
housing for more thorough cleaning.
CLEANING THE DUST BOWLS AND FILTERS
• The dust bowls and filters can be washed in warm soapy water.
• Make sure that the filters and the dust bowl are dry before re-fitting.
NOZZLE / ACCESSORIES
• Figure H -
A crevice tool is built into the nozzle
and can be extended by pulling the extension piece
until it locks into position.
H
G
G1
G1
E
F
F2
F1
