4
ENGLISH
(Original instructions)
u
Regularly check the power lead and
connector for damage. If the supply
cord or connector is damaged, it must
be replaced by the manufacturer or
an authorised Black & Decker Service
Centre in order to avoid a hazard.
u
Never attempt to remove or replace
any parts other than those specied in
this manual.
Additional safety instructions
After use
u Unplug the charger before cleaning the charger or charg-
ing base.
u When not in use, the appliance should be stored in a dry
place.
u Children should not have access to stored appliances.
Residual risks.
Additional residual risks may arise when using the tool which
may not be included in the enclosed safety warnings. These
risks can arise from misuse, prolonged use etc.
Even with the application of the relevant safety regulations
and the implementation of safety devices, certain residual
risks can not be avoided. These include:
u Injuries caused by touching any rotating/moving parts.
u Injuries caused when changing any parts, blades or ac-
cessories.
u Injuries caused by prolonged use of a tool. When using
any tool for prolonged periods ensure you take regular
breaks.
u Impairment of hearing.
u Health hazards caused by breathing dust developed when
using your tool (example:- working with wood, especially
oak, beech and MDF.)
Electrical safety
The appliance is designed for use with 12 V negative ground
vehicle battery systems.
Warning! The cigarette lighter connector is tted with a non-
serviceable safety fuse. The fuse may operate in the event of
a fault. If this occurs the fuse must be replaced together with
the connector and cable by the manufacturer or an authorised
Black and Decker Service Centre in order to avoid a hazard.
Warning! Do not operate the appliance with systems which
have positive ground or a different voltage.
Symbols on the appliance
Read all of this manual carefully before using the
appliance.
Features
This tool includes some or all of the following features.
1. On/off switch
2. Bowl release button
3. Dust bowl
4. Nozzle (ADV1220 only)
5. 12V car connector
Fig. A (ADV1210 only)
6. Brush head
7. Crevice tool
Fig. B (ADV1220 only)
8. Large brush head
9. Large crevice tool
10. Flexible hose
Assembly
Accessories (g. A & B)
These models may be supplied with some of the following
accessories:
u Brush head (6) (ADV1210 only).
u Crevice tool (7) (ADV1210 only).
u Large brush head (8) (ADV1220 only).
u Large crevice tool (9) (ADV1220 only).
u Flexible hose (10) (ADV1220 only).
Fitting the accessories (Fig. A) (ADV1210 only)
u Insert the appropriate accessory into the front of the appli-
ance. Make sure that the accessory is pushed fully in.
Fitting the accessories (Fig. B) (ADV1220 only)
u Fit the appropriate accessory on to the short end of the
flexible hose (10). Make sure that the accessory is pushed
fully on.
u Fit the long end of the flexible hose (10) into the front of
the appliance. Make sure that the flexible hose is pushed
fully in.
Use
Connecting to the vehicle’s power supply
u Make sure that the appliance is switched off.
u Remove the cigarette lighter from it’s socket.
u Plug the 12V car connector (5) into the cigarette lighter
socket.
